Field Start-up
Information Manual 39
Local Atmospheric Pressure
The range of settings is 10 to 16 psig in increments
of 1 or 0.1 psig or kPa depending on the Service
Setup Screen xxx or xxx.x. The Factory Default is
14.7 psig.
Refrigerant Pressure Analog Output
Option
Possible values for status are: % Cond (Factory
Default) and Delta.
Min Delta Pressure Calibration
The following is displayed only if the “Refrigerant
Pressure Analog Output Option” is set to “Delta”.
The range of values is 0-400 psid (0-2758 kPa) in
increments of 1 psid/kPa. Factory Default is 0 psid (0
kPa).
Note: 6.8948 kPa = 1 psi.
Max Delta Pressure Calibration
The following is displayed only if the “Refrigerant
Pressure Analog Output Option” is set to “Delta”.
The range of values is 1-400 psid (7-2758 kPa) in
increments of 1 psid/kPa. Factory Default is 30 psid
(207 kPa).
Note: 6.8948 kPa = 1 psi.
IGV Stroke Time
The following is displayed only if the “Inlet Guide
Vane Output” is set to “Pulsed”.
The range of values is 15 to 100 seconds in
increments of 1 second. Default is 45 seconds.
Low Differential Oil Pressure Cutout
This screen is displayed only if the “Oil Pressure
Protection” is “Transducer”.
The range of values is 9 to 35 psid in increments of 1
psid. Default is 12 psid.
Check Oil Filter Diagnostic
This screen is available only if differential oil pressure
transducer(s) are installed.
Possible values of [setting] are: Disable (Factory
Default) and Enable.
Check Oil Filter Setpoint
This screen is displayed only if differential oil
pressure transducer(s) are installed and check oil
filter diagnostic is enabled.
Possible values of [setting] are: 9 to 60 psid in 1 psid
increments. Factory Default is 15 psid.
Local Atmospheric Pressure: xx.x psia/kpa
Press (+)(-) to Change Setting
Rfgt Pressure Output Option: [status]
Press (+)(-) to Change Setting
Min Delta Press Calib (2 VDC):XXXXPSID/kPa
Press (+)(-) to Change Setting
Max Delta PressCalib (10 VDC):XXXXPSID/kPa
Press (+)(-) to Change Setting
Inlet Guide Vane Stroke Time: XXX Sec
Press (+)(-) to Change Setting
Low Diff Oil Press Cutout: XX psid/kpa
Press (+)(-) to Change Setting
Check Oil Filter Diagnostic: [setting]
Press (+)(-) to Change Setting
Check Oil Filter Setpt: [setting]
Press (+)(-) to Change Setting
