CVHE-SB-32A 76
Table 20
Outdoor Air Temp.
A2 Analog Input
Thermistor Accuracy = 0.90°°F from -10 to 0°°F
Thermistor Accuracy =0.540°°F from 0 to 700°°F
Thermistor Accuracy = 1.80°°F from 70 to 150°°F
Type U Thermistor Temperature Versus Resistance and Terminal Voltage Table for a
pullup resistor of 6980 Ohms.
Used to sense temperatures at the following point:
1. Outdoor Air Temp. CVHE/F/G
Table 20
Temp °°F Min Res Max Res Min Vterm Max Vterm
-10.0 117759 124893 4.713 4.729
-5.0 99928 105882 4.666 4.685
0.0 86006 89016 4.617 4.630
5.0 73347 75873 4.557 4.573
10.0 62706 64832 4.490 4.508
15.0 53738 55532 4.416 4.435
20.0 46161 47678 4.333 4.355
25.0 39742 41029 4.242 4.266
30.0 34292 35386 4.143 4.169
35.0 29713 30628 4.037 4.065
40.0 25830 26611 3.923 3.953
45.0 22512 23180 3.803 3.835
50.0 19668 20242 3.675 3.709
55.0 17225 17718 3.542 3.578
60.0 15120 15546 3.404 3.441
65.0 13303 13670 3.262 3.300
70.0 11367 12410 3.083 3.190
75.0 10049 10956 2.935 3.044
80.0 8903 9692 2.787 2.896
85.0 7903 8592 2.640 2.748
90.0 7029 7632 2.494 2.601
95.0 6264 6792 2.350 2.456
100.0 5592 6056 2.210 2.313
To Next Page
