60 Direct-Fired Make-up Air • MUA-SVX01A-EN
Maintenance
Figure 20. Gas burner section view
Flame Rod
71.0201.06
Spark Ignitor
65.0910.28
Pilot Tubing
(when required)
Gas Manifold
65.0910.28
Gas Manifold
Plan View
(Burner Plates Removed)
Pin Vise
#45 Drill
1“
Gas Manifold
1/8”
