MUA-SVX006B-EN
35
Start-Up
Before starting the unit, use the “Gas Equipment Start Up Sheet” (located at the end of this
manual) and read the Separated Combustion Indoor Duct Furnace Manual entirely in conjunction
with the procedures outlined below to ensure that the unit is completely and properly installed
and ready for start up.
WWAARRNNIINNGG
CChheecckk ooff SSaaffeettyy DDeevviicceess RReeqquuiirreedd!!
FFaaiilluurree ttoo ddoo ffoollllooww iinnssttrruuccttiioonnss bbeellooww ccoouulldd ccaauussee uunnssaaffee ccoonnddiittiioonnss aanndd rreessuulltt iinn ddeeaatthh,,
sseerriioouuss iinnjjuurryy oorr pprrooppeerrttyy ddaammaaggee..
AAllll ssaaffeettyy ccoonnttrroollss MMUUSSTT bbee cchheecckkeedd bbeeffoorree ssttaarrttiinngg tthhee uunniitt aanndd dduurriinngg rreegguullaarr
mmaaiinntteennaannccee!! CChheecckk aanndd tteesstt tthhee ooppeerraattiioonnaall ffuunnccttiioonnss ooff aallll ssaaffeettyy ddeevviicceess ssuupppplliieedd wwiitthh
tthhiiss uunniitt..
1. Inspect all wiring connections; connections should be clean and tight. TTrraaccee cciirrccuuiittss ttoo
iinnssuurree tthhaatt aaccttuuaall wwiirriinngg aaggrreeeess wwiitthh tthhee ““aass wwiirreedd”” ddiiaaggrraammss pprroovviiddeedd wwiitthh tthhee uunniitt.
Information in the wiring diagram title block should match the data appearing on the unit
nameplate.
2. Lubricate all electrical motors according to the manufacturer’s recommendations.
3. Verify that the system switch is in the OFF position.
4. Check unit supply voltage to ensure that it is within the utilization range.
5. Inspect the interior of the unit; remove any debris or tools which may be present.
SSttaarrttiinngg tthhee UUnniitt iinn HHeeaattiinngg MMooddee
1. Close the unit disconnect switch which provides power to the unit.
IImmppoorrttaanntt:: High voltage is present in some areas of the unit (primarily the main electrical
cabinet) with the unit disconnect switch closed. Failure to exercise caution when
working in the presence of energized electrical components may result in injury or
death from electrical shock.
WWAARRNNIINNGG
LLiivvee EElleeccttrriiccaall CCoommppoonneennttss!!
FFaaiilluurree ttoo ffoollllooww aallll eelleeccttrriiccaall ssaaffeettyy pprreeccaauuttiioonnss wwhheenn eexxppoosseedd ttoo lliivvee eelleeccttrriiccaall
ccoommppoonneennttss ccoouulldd rreessuulltt iinn ddeeaatthh oorr sseerriioouuss iinnjjuurryy..
WWhheenn iitt iiss nneecceessssaarryy ttoo wwoorrkk wwiitthh lliivvee eelleeccttrriiccaall ccoommppoonneennttss,, hhaavvee aa qquuaalliiffiieedd lliicceennsseedd
eelleeccttrriicciiaann oorr ootthheerr iinnddiivviidduuaall wwhhoo hhaass bbeeeenn pprrooppeerrllyy ttrraaiinneedd iinn hhaannddlliinngg lliivvee eelleeccttrriiccaall
ccoommppoonneennttss ppeerrffoorrmm tthheessee ttaasskkss..
2. Set the thermostat/switching subbase as indicated below:
a. Position the heating system switch at either HEAT or AUTO;
b. Set the fan switch to AUTO.
3. Place the system switch in the ON position.
NNoottee:: With the thermostat calling for heat, unit operation is automatic.
SSttaarrttiinngg UUnniitt iinn CCoooolliinngg MMooddee
1. Close the unit disconnect switch which provides power to the unit.
IImmppoorrttaanntt:: High voltage is present in some areas of the unit (primarily the main electrical
cabinet) with the unit disconnect switch closed. Failure to exercise caution when
working in the presence of energized electrical components may result in injury or
death from electrical shock.
2. Set the thermostat/switching subbase as indicated below:
a. Position the cooling system switch at either COOL or AUTO;
b. Set the fan switch to AUTO.
