Table 6. Cooling Coil Weight Adder (Approximate)
Capacity
DX COIL
4 Row 6 Row
10, 15
97 lbs. 132 lbs.
20, 25, 50
126 lbs. 177 lbs.
30, 35, 60, 70
165 lbs. 229 lbs.
40, 80
177 lbs. 249 lbs.
Capacity
CHILLED WATER COIL
4 Row 6 Row
10, 15
75 lbs. 102 lbs.
20, 25, 50
98 lbs. 135 lbs.
30, 35, 60, 70
125 lbs. 176 lbs.
40, 80
135lbs. 196 lbs.
Table 7. VFD Enclosure Weight Adder
Small Enclosure, VFD 1–5 HP
95 lbs.
Large Enclosure, VFD 7.5–15 HP
135 lbs.
Table 8. Indoor Arrangement “A, B, D, G, K” Shipping Weights (lbs.)
Capacity
Arrangement Outside Air
Hood w/Bird
Screen
Weight Adder
A B D G K
10 742 904 1137 43
15 739 956 1188 43
20 916 1102 1206 1394 51
25 957 1114 1249 1436 51
30 1092 1301 1452 1659 59
35 1143 1352 1495 1702 59
40 1222 1443 1583 1799 63
50 550 1423 1595 1689 1915 51
60 650 1616 1812 1951 2195 59
70 800 1707 1902 2033 2278 59
80 850 1833 1240 2166 2420 63
12 1300 2741 63
Note: The approximate shipping weights are for a basic unit (these weights do not include the motor, cooling coil,
optional outside air hood, flex connector kit, or any options). For units with double wall construction, add an
additional 10% of the base unit weight.
AApppprrooxxiimmaattee MMoottoorr SShhiippppiinngg WWeeiigghhttss
