TAM828
MONITOR MENU
EEV POSITION
XXX / YYY STEPS
COIL TEMP
XXX F
GAS TEMP
XXX F
SUPERHEAT
XXX F
AIRFLOW DATA
<Control Mode>
MOTOR DATA
EXT STAT PRESS
XX.XX IN CALC
LVG COIL AIR T
XXX F
HUMIDIFIER
ON/OFF
EXTERNAL SW
CLOSED/OPEN
CONDENS SW
CLOSED/OPEN
AUX HEAT DMD
XXX %
DEMAND AIRFLOW
XXXX CFM
CALC AIRFLOW
XXXX CFM ESP
MOTOR SPEED
XXXX RPM
MOTOR TORQUE
XXX%
SYSTEM TIME
DDDD:HH:MM:SS
CYCLE TIME
COOL RUN TIME
XXXXXX HRS
HP RUN TIME
XXXXXX HRS
AUX RUN TIME
XXXXXX HRS
EXT SW ACTION
IGNORE
ALERT
menu
CYCLE COUNT
COOL CYCLES
XXXXXX COUNT
HP CYCLES
XXXXXX COUNT
AUX CYCLES
XXXXXX COUNT
CONTROL
menu
EH RELAYS
H2O TEMP IN
XXX F
H2O TEMP OUT
XXX F
HH RELAY
OR
Monitor Menu
Technician Monitor Menu
The Monitor menu allows the technician to monitor the
different aspects of the system while the air handler is
running. No changes can be made in the Monitor Menu.
• Superheat is only shown in cooling and defrost modes
• Airflow Data
o The letters ESP (External Static Pressure) will
appear when the control mode of the motor is
Constant Torque; and the calculated CFM is greater
than 50 CFM from the demand. (Allow 90 seconds
for the motor ramping process to end to verify that
the motor cannot achieve the demand airflow)
• AUX HEAT DMD is only shown when an electic heat or
hydronic heat control has been detected.,
• EH RELAYS is only shown when an electric heat control
has been detected.
• H20 TEMP IN is only shown when a hydronic heat con-
trol has been detected.
• COIL TEMP is calculated (CALC) during the cooling
and defrost modes.
General Notes:
When EHC is detected, boxes represent:
o = element configured but not energized
n = element configured and energized
o = element faulty, may or may not be
energized
