Trane IntelliPak SAHL Series User Manual

128 RT-SVX36G-EN
Unit Start Up
Table 42. 90-130 Tons modulating 100% exhaust fan performance
Cfm Negative Static Pressure
Nominal Std 0.250 0.500 0.750 1.000 1.250 1.500 1.750 2.000 2.250 2.500
Tons Air RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP
90-130
28000 516 11.42 551 12.41 586 13.70 622 15.25 657 16.71 690 18.16 723 19.90 754 21.74 785 23.60 815 25.45
30000 550 13.94 579 14.86 614 16.25 646 17.72 680 19.45 712 20.93 743 22.54 773 24.41 803 26.38 832 28.36
32000 583 16.82 609 17.68 642 19.12 672 20.58 704 22.34 735 24.12 764 25.67 793 27.42
822 29.41 850 31.50
34000 617 20.09 640 20.92 670 22.30 700 23.87 728 25.53 759 27.51 788 29.30 815 30.96
842 32.82 869 34.93
36000 650 23.76 672 24.58 699 25.86 728 27.55 755 29.19 782 31.11 811 33.21
838 35.05 864 36.81 889 38.77
38000 684 27.86 704 28.68 728 29.87 757 31.60 783 33.33 808 35.14
834 37.30 861 39.48 887 41.38 911 43.23
40000
718 32.41 737 33.24 758 34.36 785 36.02 811 37.91 835 39.71 859 41.74 885 44.08 910 46.33 934 48.32
Notes:
1. Shaded areas indicate non-standard drive selections. These drive selections must be manually factory selected.
2. Refer to General Data Table for minimum and maximum hp's.
Table 43. 20-89 tons - 50% exhaust fan performance
Cfm Negative Static Pressure (In. W.G.)
Nominal Std 0.200 0.400 0.600 0.800 1.000 1.200 1.400
Tons
(AC/EC) Air RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP
20/25
24/29
2000
364 0.17 487 0.30 582 0.45 658 0.58 731 0.73 797 0.90 856 1.08
3000
435 0.36 522 0.51 614 0.67 694 0.88 765 1.11 830 1.34 886 1.54
4000 529 0.76 592 0.86 654 1.03 728 1.29 797 1.51 861 1.77 919 2.05
5000 623 1.32 687 1.56 735 1.67 778 1.79 836 2.13 896 2.45 953 2.72
6000 722 2.13 779 2.47 830 2.72 870 2.86 905 2.96
30/36
2000
364 0.17 487 0.30 582 0.45 658 0.58 731 0.73 797 0.90 856 1.08
3000
435 0.36 522 0.51 614 0.67 694 0.88 765 1.11 830 1.34 886 1.54
4000
529 0.76 592 0.86 654 1.03 728 1.29 797 1.51 861 1.77 919 2.05
5000 623 1.32 687 1.56 735 1.67 778 1.79 836 2.13 896 2.45 953 2.72
6000 722 2.13 779 2.47 830 2.72 870 2.86 905 2.96 944 3.16 994 3.59
7000 824 3.23 874 3.64 922 4.02 965 4.30 1000 4.48 1032 4.59 1062 4.72
40/48
3000
288 0.22 393 0.38 477 0.55 547 0.74 611 0.94 668 1.16 721 1.39
5000
372 0.66 430 0.83 495 1.05 557 1.29 621 1.57 680 1.87 732 2.16
7000 472 1.55 522 1.82 563 2.04 606 2.29 653 2.59 698 2.91 742 3.24
9000 578 3.06 621 3.41 661 3.76 695 4.06 725 4.34 758 4.65 794 5.01
11000 688 5.36 725 5.80 760 6.24 793 6.66 823 7.06 850 7.42 875 7.76
50/55/59
3000
288 0.22 393 0.38 477 0.55 547 0.74 611 0.94 668 1.16 721 1.39
5000
372 0.66 430 0.83 495 1.05 557 1.29 621 1.57 680 1.87 732 2.16
7000
472 1.55 522 1.82 563 2.04 606 2.29 653 2.59 698 2.91 742 3.24
9000 578 3.06 621 3.41 661 3.76 695 4.06 725 4.34 758 4.65 794 5.01
11000 688 5.36 725 5.80 760 6.24 793 6.66 823 7.06 850 7.42 875 7.76
60/73
4000
271 0.29 364 0.54 438 0.82 499 1.07 550 1.30 601 1.56 651 1.87
6000
339 0.71 391 0.90 456 1.22 517 1.60 572 2.01 622 2.43 668 2.85
8000 425 1.55 460 1.73 497 1.96 542 2.30 591 2.72 639 3.20 684 3.73
10000 517 2.88 543 3.13 571 3.34 600 3.59 632 3.94 668 4.37 707 4.87
12000 612 4.84 633 5.15 655 5.43 678 5.68 702 5.95 726 6.29 752 6.71
13000 659 6.09 679 6.44 699 6.76 720 7.04 741 7.31
