RT-SVX36G-EN 129
Unit Start Up
70/75
80/89
4000
271 0.29 364 0.54 438 0.82 499 1.07 550 1.30 601 1.56 651 1.87
6000
339 0.71 391 0.90 456 1.22 517 1.60 572 2.01 622 2.43 668 2.85
8000
425 1.55 460 1.73 497 1.96 542 2.30 591 2.72 639 3.20 684 3.73
10000 517 2.88 543 3.13 571 3.34 600 3.59 632 3.94 668 4.37 707 4.87
12000 612 4.84 633 5.15 655 5.43 678 5.68 702 5.95 726 6.29 752 6.71
13000 659 6.09 679 6.44 699 6.76 720 7.04 741 7.31
Note: Shaded areas indicate non-standard drive selections. These drive selections must be manually factory selected.
Table 43. 20-89 tons - 50% exhaust fan performance
Table 44. 90-130 Tons - 50% exhaust fan performance
Cfm Negative Static Pressure (In. W.G.)
Nom Std 0.250 0.500 0.750 1.000 1.250 1.500 1.750 2.000 2.250 2.500
Tons Air RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP
90-130
12000 452 3.68 495 4.21 536 4.85 576 5.46 614 6.17 651 6.95 687 7.73 722 8.55 759 9.46 797 10.45
14000 516 5.71 551 6.21 586 6.85 622 7.63 657 8.36 690 9.09 723 9.96 754 10.88 785 11.79 815 12.72
16000 583 8.41 609 8.85 643 9.57 672 10.29 704 11.18 735 12.07 764 12.84 793 13.72 822 14.72
850 15.76
18000 650 11.88 672 12.29 699 12.94 729 13.79 755 14.59
782 15.56 811 16.62 838 17.53 864 18.41 889 19.39
20000
718 16.20 737 16.62 758 17.18 785 18.03 811 18.97 835 19.86 859 20.87 885 22.05 910 23.18 934 24.17
Note: Shaded areas indicate non-standard drive selections. These drive selections must be manually factory selected.
