Trane Koolman R410A - Page 13

13
PKGP-SVX03D-EN
Installation
Figure 4. Installation diagram for typical piping accessories (the model of this diagram is CGAR100)
Make-up water
Water intake
Oil-return inlet
Automatic air vent
Manual gate valve
Balancing valve ball valve
Thermometer
Flow switch
Shockproof hose
Filter
Expansion tank
Manual gate valve
Manometer
Water intake
Water outlet
Shockproof gasket
