Trane LonWorks TR200 User Manual

Background Knowledge
The Trane LonWorks option card is designed to communicate with any system complying with the FTT and 78
Kbps LonWorks standard. Familiarity with this technology is assumed. Issues regarding hardware or software
produced by other manufacturers, including commissioning tools, are beyond the scope of this manual and are
not the responsibility of Trane.
For information regarding commissioning tools or communication with a non-Trane node, please consult the
appropriate manuals.
Related Literature for the TR200
The following literature is available for the TR200 series:
Title Literature no.
TR200 Instruction Manual MG.12.H1x.yy
TR200 Drive Design Guide MG.12.I1x.yy
TR200 Drive Programming Guide MG.12.J1x.yy
Please also refer to www.trane.com/vfd for additional information.
LonMark Certification
The LonWorks option is conform to the LonMark standards and is certified towards LonMark ver. 3.4
Introduction
3-2 TR200 LonWorks

Trane LonWorks TR200 Specifications

General

Communication Protocol	LonWorks
Frequency Range	50/60 Hz
Enclosure Rating	NEMA 1
Category	Industrial Equipment
Operating Temperature Range	-10°C to 50°C
Display	LCD
Mounting	Wall Mount
Drive Type	Variable Frequency Drive
Control Method	Sensorless Vector Control
Type	Variable Frequency Drive
Humidity Range	5% to 95% (non-condensing)
