16 AMS-SVX03A-EN
DIP setting
Indoor unit address DIP
Different indoor units must have different address DIP (Same indoor unit address DIP may
cause confl icts).
There are total 8 DIP switches for SW1 at the control board, S1, S2, S3 and S4 are address DIP
switches as followings:
S1 S2 S3 S4 Indoor unit address
0000 1
0001 2
0010 3
0011 4
0100 5
0101 6
0110 7
0111 8
Note:
1. Indoor unit address setting can be divided into automatic and manual setting, two
kinds.
2. Manual setting sees the table above, automatic addressing take automatic addressing
process in the outdoor unit instruction manual for reference.
