AMS-SVX03A-EN 15
DIP setting
Wall-mounted indoor unit PCB board DIP setting
SW2
Indoor unit capacity DIP Reserved
Indoor fan gear
selection
Reserved
S1 S2 S3 S4 S5 S6 S7 S8
SW1
Indoor unit address DIP Reserved Reserved Test program
S1 S2 S3 S4 S5 S6 S7 S8
Indoor unit capacity DIP
According to the capacity, the indoor unit is divided into various models, such as 2.8kW, 3.6kW
and 5.0kW etc. Capacity DIP at the control board decides the capacity.
There are total 8 DIP switches for SW2 at the control board, S1, S2, S3 and S4 are capacity DIP
switches as followings:
S1 S2 S3 S4
Indoor unit capacity
DŽkWDž
0000 2.8
0001 3.6
0010 5.0
Indoor unit fan speed gear selection
Correct indoor unit connecting pipe length through the unit DIP switches. There are 8 DIP
switches for SW2 at indoor unit control board and S7 decides indoor unit fan speed gear. When
the DIP is Đ0đ, itďs high three gears for high, medium and low, when the DIP is Đ1đ, itďs low
three gears for medium, low and extra-low.
Indoor unit fan speed gear High three gears Low three gears
Indoor unit fan speed gear S7 0 1
Indoor unit fan speed High, medium and low Medium, low and extra-low
