Trane Precedent TSCSeries User Manual

Unit Wiring Diagrams Numbers
60 RT-SVX22J-EN
Connection
Reliatel
230V
4366-7336 THC(037) (230V)
4366-7338 THC(047-067) (230V)
4366-4559 T(S,H)C(036-060)E,F (1-Phase), ReliaTel Controls
4366-5182 THC(036-060)E,F (3-Phase), ReliaTel Controls, X13 IDM
4366-1509
T(S,H)C(036-060)E,F (3-Phase), ReliaTel Controls, Belt-Drive
IDM
4366-1541 T(S,H)C(072,090)F, ReliaTel Controls
4366-7441 THC(092-120)E, ReliaTel Controls
4366-1534 TSC(092,102)F, ReliaTel Controls
4366-7443 TSC120F, ReliaTel Controls
460V and/or
575V
4366-7337 THC(037) (460V)
4366-7339 THC(047-067) (460V)
4366-5182 THC(036-060)E,F (3-Phase), ReliaTel Controls, X13 IDM
4366-1509
T(S,H)C(036-060)E,F (3-Phase), ReliaTel Controls, Belt-Drive
IDM
4366-1541 T(S,H)C(072,090)F, ReliaTel Controls
4366-7441 THC(092-120)E, ReliaTel Controls
4366-1534 TSC(092,102)F, ReliaTel Controls
4366-7443 TSC120F (460V), ReliaTel Controls
4366-7445 TSC120F (575V), ReliaTel Controls
Electromechanical
230V
4366-4558 T(S,H)C(036-060)E,F (1-Phase), Electromechanical Controls
4366-5181
THC(036-060)E,F (3-Phase), Electromechanical Controls, X13
IDM
4366-1524
T(S,H)C(036-060)E,F (3-Phase), Electromechanical Controls,
Belt-Drive IDM
4366-1536 T(S,H)C(072,090)F, Electromechanical Controls
4366-6842 THC(092-120)E, Electromechanical Controls
4366-1533 TSC(092,102)F, Electromechanical Controls
4366-6863 TSC120F (230V), Electromechanical Controls
460V and/or
575V
4366-5181
THC(036-060)E,F (3-Phase), Electromechanical Controls, X13
IDM
4366-1524
T(S,H)C(036-060)E,F (3-Phase), Electromechanical Controls,
Belt-Drive IDM
4366-1536 T(S,H)C(072,090)F, Electromechanical Controls
4366-6842 THC(092-120)E, Electromechanical Controls
4366-1533 TSC(092,102)F, Electromechanical Controls
4366-6863 TSC120F (460V), Electromechanical Controls
4366-6864 TSC120F (575V), Electromechanical Controls
Table 16. Unit wiring diagram numbers (continued)
Schematic Type Drawing Number Description
