Fig. 4.37
Fig. 4.38 Fig. 4.39
Fix connection cord and power cord by cord clamp
After passing the connection cord and power cord through the insulation tube, fasten it with the
cord clamp. (Fig. 4.39)
WARNING!
(1) Before starting work, check that power is not being supplied to the indoor unit and outdoor
unit.
(2) Improperly installed field wiring poses fire and electrocution hazards. Pay special attention to
the wiring of the units.
(3) Connect the connection cords firmly to the terminal block. Improper installation may cause a
fire.
(4) Always fasten the outside covering of the connection cord with cord clamps. (If the insulator is
not clamped, electric leakage may occur.)
(5) Always connect the ground wire.
MS-SVN043-EN
