System Appearance - LCD model
7
MCW-SVU03A-E4
Indoor unit
Air in
Surface panel
Air cleaner
Filter
Handling switch
Wiring cover
Liquid crystal
displayer
Louver
Power plug
Drain hose
Big handle
Air outlet cover
Wireless remote
controller
1
1
2
3
2
3
4
4
4
5
5
6
6
6
7
7
8
8
9
9
10
11
12
12
Air out
STOP
RUN
AUTO
TEST
*Operating indicator (GREEN) light up when the unit is on, and flashing when
the unit is defrosting.
LCD Model
12/18MBh
MCW512R1
MCW518R1
