Table 17 - RTUD R134a (Continued)
Unit size 180 180 190 190 200 200 220 220 250 250 260 270
Unit Type Digit 12 2 2 1 1 2 2 2 2 2 2 2 2
Unit Application Digit 15 D;E D;E D;E D;E D;E D;E D;E D;E D;E D;E D;E D;E
Evap Application Digit 21 * * * * * * * * * * * *
Comp Starter digit 24 Y B Y B Y B Y B Y B B B
Compressor C1 M2 HiVi M2 HiVi N1 HiVi N1 HiVi N1 HiVi N1 HiVi N1 HiVi N1 HiVi N2 HiVi N2 HiVi N1 60 HiViN2 60 HiVi
C2 N1 HiVi N1 HiVi N2 HiVi N2 HiVi N1 HiVi N1 HiVi N2 HiVi N2 HiVi N2 HiVi N2 HiVi N2 60 HiViN2 60 HiVi
Circuit 1 Motor RLA (A) 132.8 132.8 160.8 160.8 160.8 160.8 160.8 160.8 192.0 192.0 194.4 234.4
Motor LRA (A) 259.0 0.0 291.0 0.0 291.0 0.0 291.0 0.0 354.0 0.0 0.0 0.0
Max Amps (A) 166.0 153.3 201.0 188.1 201.0 188.1 201.0 188.1 240.0 223.6 225.3 267.9
Max Power input (kW) 98.9 100.9 121.3 123.8 121.3 123.8 121.3 123.8 144.2 147.1 148.3 176.3
Circuit 2 Motor RLA (A) 160.8 160.8 192.0 192.0 160.8 160.8 192.0 192.0 192.0 192.0 234.4 234.4
Motor LRA (A) 291.0 0.0 354.0 0.0 291.0 0.0 354.0 0.0 354.0 0.0 0.0 0.0
Max Amps (A) 201.0 188.1 240.0 223.6 201.0 188.1 240.0 223.6 240.0 223.6 267.9 267.9
Max Power input (kW) 121.3 123.8 144.2 147.1 121.3 123.8 144.2 147.1 144.2 147.1 176.3 176.3
Unit @ Max Starting Amps (A) 462.0 343.4 557.0 413.6 494.0 378.1 557.0 413.6 596.0 449.1 495.2 537.8
Amps ctl + auxiliaires 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0
Max. Amps (A) 369.0 343.4 443.0 413.6 404.0 378.1 443.0 413.6 482.0 449.1 495.2 537.8
displacement power
factor (DPF)
0.87 0.95 0.87 0.95 0.87 0.95 0.87 0.95 0.87 0.95 0.95 0.95
short circuit withstand
rating (kA)
35 35 35 35 35 35 35 35 35 35 35 35
Disconnect
Switch
Digit 26=C
Fuse size (A) C1 200 aM-T2200 gG-T2250 aM-T2250 aM-T2250 aM-T2250 aM-T2250 aM-T2250 aM-T2315 aM-T2315 aM-T2315 aM-T2315 aM-T2
Fuse size (A) C2 250 aM-T2250 aM-T2315 aM-T2315 aM-T2250 aM-T2250 aM-T2315 aM-T2315 aM-T2315 aM-T2315 aM-T2315 aM-T2315 aM-T2
Disconect Switch Size 6X400A -
T2
6X400A -
T2
6X400A -
T2
6X400A -
T2
6X400A -
T2
6X400A -
T2
6X400A -
T2
6X400A -
T2
6X400A -
T2
6X400A -
T2
6X400A -
T2
6X400A -
T2
Max connecting Wire
(mm²)
2 x 240 2 x 240 2 x 240 2 x 240 2 x 240 2 x 240 2 x 240 2 x 240 2 x 240 2 x 240 2 x 240 2 x 240
Bus bar width (mm) 45 45 45 45 45 45 45 45 45 45 45 45
Circuit Breaker +
Bus bar
Digit 26=D
circuit breaker size
(A) C1
NSX 250A NSX 250A NSX 400A NSX 400A NSX 250A NSX 250A NSX 400A NSX 400A NSX 400A NSX 400A NSX 400A NSX 400A
circuit breaker size
(A) C2
NSX 250A NSX 250A NSX 400A NSX 400A NSX 250A NSX 250A NSX 400A NSX 400A NSX 400A NSX 400A NSX 400A NSX 400A
Bus bar connection Copper
bar 50x8
Copper
bar 50x8
Copper
bar 50x10
Copper
bar 50x10
Copper
bar 50x8
Copper
bar 50x8
Copper
bar 50x10
Copper
bar 50x10
Copper
bar 50x10
Copper
bar 50x10
Copper
bar 50x10
Copper
bar 50x10
Max connecting Wire
(mm²)
2 x 240 2 x 240 2 x 240 2 x 240 2 x 240 2 x 240 2 x 240 2 x 240 2 x 240 2 x 240 2 x 240 2 x 240
