Trane RTWB Helical-Rotary User Manual

RTWB-SVN01B-E4
17
Installation Mechanical
Table 4 –Evaporator and condenser data
Evaporator water content Condenser water content
Model RTWB Evaporator code Condenser code Liter Liter
207 EG 120 CG 120 105 60
208 EG 120 CG 120 105 60
210 EG 140 CG 140 265 55
211 EG 170 CG 170 220 66
212 EG 170 CG 170 220 66
212 EG 170 CG 170 220 66
214 EG 200 CG 200 200 75
216 EG 200 CG 200 200 75
217 EG 200 CG 200 200 75
218 EG 250 CG 230 415 78
220 EG 250 CG 230 415 78
222 EG 340 CG 230 560 78
224 EG 340 CG 230 560 78
Minimum and maximum evaporator water flow (L/s)
Evaporator Code Pass Number Minimum Water Flow Maximum Water Flow Connection Diameter (in.)
EG 120 1 4.5 13.4 5
EG 140 1 6.0 18.0 6
EG 170 1 7.0 21.0 6
EG 200 1 9.0 25.0 6
EG 250 1 11.0 33.0 6
EG 340 1 14.0 43.0 6
Minimum and maximum condenser water flow (L/s)
Condenser Code Pass Number Minimum Water Flow Maximum Water Flow Connection Diameter (in.)
CG 120 1 8.4 31.0 5
CG 140 1 9.5 34.9 5
CG 170 1 11.9 43.7 5
CG 200 1 17.0 61.0 5
CG 230 1 17.0 61.0 5
Table 5 – RTWB Evaporator water pressure drop (kPa)
Water flow (L/s)
Model RTWB 5 10 15 20 25 30 35 40 45
207 1 6 24 - -
208 1 6 24 - -
210 1 - 57 122 -
211 1 - 29 61 104
212 1 - 29 61 104
214 1 11 24 41 62
216 1 11 24 41 62
217 1 11 24 41 62
218 1 17 29 45 64
220 1 17 29 45 64
222 1 23 35 49 66 85 106
224 1 23 35 49 66 85 106
Table 6 – RTWB Condenser water pressure drop (kPa)
Water flow (L/s)
Model RTWB 10 15 20 25 30 35 40 45 50 55 50
207 1 1020345171 - -
208 1 1020345171 - -
210 1 6 12 20 30 42 -
211 1 - 8 14 21 29 38 48
212 1 - 8 14 21 29 38 48
214 1 12 18 24 32 40 48 58 68 79
216 1 12 18 24 32 40 48 58 68 79
217 1 12 18 24 32 40 48 58 68 79
218 1 12 18 24 32 40 48 58 68 79
220 1 12 18 24 32 40 48 58 68 79
222 1 12 18 24 32 40 48 58 68 79
224 1 12 18 24 32 40 48 58 68 79
Pass
Number
Pass
Number
