Table 1 – Installation overview
Refer to the installation mechanical and electrical sections of this manual for detailed installation instructions.
Requirement Trane supplied Trane supplied Field supplied
Trane installed Field installed Field installed
Rigging Safety chains
Clevis connectors
Lifting beam
Isolation Isolation pads Isolation pads
Electrical Disconnect switch (optional) Disconnect switch
Flow switches (may be field supplied) BAS wiring (optional)
Water pump contactor
Water piping Flow switches (may be field supplied) Thermometers
Water flow pressure gauges
Isolation and balancing valves water piping
Vents and drain valves
Pressure relief valves
Pressure relief Relief valves Vent line
Insulation Insulation (optional) Insulation
Table 2 - General data
207 208 210 211 212 214 216 217 218 220 222 224
Evaporator type EG 120 EG 120 EG 140 EG 170 EG 170 EG 200 EG 200 EG 200 EG 250 EG 250 EG 340 EG 340
Condenser type CG 120 CG 120 CG140 CG 170 CG 170 CG 200 CG 200 CG 200 CG 230 CG 230 CG 230 CG 230
Compressor type K1/K1 K2/K2 L1/L1 L2/L1 L2/L2 M1/M1 M2/M1 M2/M2 N1/M2 N1/N1 N2/N1 N2/N2
Oil charge (l) 6/6 6/6 7/7 7/7 7/7 8/8 8/8 8/8 8/8 8/8 11/8 11/11
Oil type OIL 023 E or OIL 048 E
Refrigerant charge
(kg) 39/39 39/39 60/60 60/60 60/60 60/60 60/60 60/60 69/69 69/69 74/74 74/74
Operating weight
(kg) 2620 2620 3370 3450 3450 3725 3725 3725 4325 4500 4925 5000
Shipping weight
(kg) 2450 2450 3050 3150 3150 3500 3500 3500 3900 4050 4250 4400
Length (mm) 2880 2880 4150 4150 4150 4150 4150 4150 4150 4150 4150 4150
Width (mm) (1) 890 890 890 890 890 890 890 890 890 890 890 890
Height (mm) (1) 1789 1789 1832 1832 1832 1832 1832 1832 1932 1932 2041 2041
(1) With compressor sound enclosure and disconnect switch handle not mounted.
