22
S8V2-SVX001-1A-EN
Table 10. S8V2C100M5P Heating Airflow
S8V2C100M5P Furnace Heating Airflow (CFM), Temp. Rise (°F), and Power (Watts) vs. External Static Pressure with
Filter (iwc)
1st Stage Capacity = 52,300
2nd Stage Capacity = 81,200
Heating
Airflow
Setting
Target
Airflow
External Static Pressure
0.1 0.3 0.5 0.7 0.9
Heating 1st
Stage
Low 979
CFM 1014 998 981 966 950
Temp. Rise
48 49 50 51 51
Watts 77 139 200 261 322
Medium Low 1080
CFM 1103 1093 1083 1073 1062
Temp. Rise
44 44 45 45 46
Watts 98 163 228 294 359
Medium
(a)
1188
CFM 1202 1190 1177 1165 1153
Temp. Rise
41 41 41 42 42
Watts 119 188 257 327 397
High
1296
CFM 1332 1314 1296 1278 1260
Temp. Rise
37 37 38 38 39
Watts 156 229 302 376 449
Heating 2nd
Stage
Low 1360
CFM 1401 1393 1385 1377 1369
Temp. Rise
54 54 54 54 54
Watts 164 249 334 419 503
Medium Low 1500
CFM 1537 1523 1509 1495 1482
Temp. Rise
49 49 49 50 50
Watts 223 313 404 494 585
Medium
(a)
1650
CFM 1673 1667 1661 1654 1649
Temp. Rise
45 45 45 45 45
Watts 285 381 478 575 671
High
1800
CFM 1825 1819 1812 1806 1800
Temp. Rise
42 41 41 42 42
Watts 371 480 588 696 805
Table 11. S8V2C100M5P Cooling Airflow
S8V2C100M5P Furnace Cooling Airflow (CFM) and Power (Watts) vs. External Static Pressure with Filter (iwc)
Outdoor Tonnage
- "Odt" (tons)
Airflow Setting -
"CPC" (CFM/ton)
EXTERNAL STATIC PRESSURE (IN. W. C.)
0.1 0.3 0.5 0.7 0.9
2.5
450
CFM / WATTS 1120 / 108 1119 / 167 1115 / 229 1109 / 294 1101 / 360
420
CFM / WATTS 1043 / 92 1041 / 148 1036 / 207 1030 / 268 1021 / 332
400
CFM / WATTS 992 / 83 989 / 136 984 / 193 976 / 252 968 / 315
370
CFM / WATTS 915 / 70 910 / 120 904 / 173 895 / 230 886 / 290
350
CFM / WATTS 863 / 62 857 / 110 850 / 161 841 / 216 831 / 275
330
CFM / WATTS 811 / 55 804 / 100 795 / 150 786 / 204 776 / 261
310
CFM / WATTS 759 / 48 750 / 92 741 / 140 730 / 192 719 / 248
290
CFM / WATTS 706 / 42 696 / 84 686 / 130 674 / 181 663 / 236
3.0
450
CFM / WATTS 1346 / 166 1348 / 236 1346 / 309 1341 / 383 1335 / 458
420
CFM / WATTS 1256 / 140 1257 / 207 1254 / 275 1249 / 345 1243 / 417
400
CFM / WATTS 1196 / 125 1196 / 188 1193 / 254 1187 / 321 1180 / 391
370
CFM / WATTS 1104 / 104 1103 / 163 1099 / 225 1093 / 288 1085 / 355
350
CFM / WATTS 1043 / 92 1041 / 148 1036 / 207 1030 / 268 1021 / 332
330
CFM / WATTS 982 / 81 979 / 134 973 / 190 965 / 249 957 / 311
310
CFM / WATTS 920 / 70 916 / 121 909 / 174 901 / 231 892 / 292
290
CFM / WATTS 858 / 61 852 / 109 844 / 160 835 / 215 825 / 274
3.5
450
CFM / WATTS 1568 / 242 1571 / 324 1570 / 407 1566 / 492 1560 / 577
420
CFM / WATTS 1465 / 204 1467 / 281 1466 / 359 1462 / 438 1456 / 519
400
CFM / WATTS 1396 / 181 1398 / 254 1396 / 329 1392 / 405 1386 / 483
370
CFM / WATTS 1291 / 150 1292 / 218 1290 / 287 1285 / 359 1279 / 432
350
CFM / WATTS 1221 / 131 1221 / 196 1218 / 262 1213 / 331 1206 / 401
330
CFM / WATTS 1150 / 114 1150 / 175 1146 / 239 1140 / 304 1133 / 372
310
CFM / WATTS 1079 / 99 1078 / 157 1073 / 217 1067 / 280 1059 / 345
290
CFM / WATTS 1007 / 85 1005 / 140 999 / 197 992 / 257 984 / 320
AAiirrffllooww TTaabblleess
