Table 11. S8V2C100M5P Cooling Airflow (continued)
S8V2C100M5P Furnace Cooling Airflow (CFM) and Power (Watts) vs. External Static Pressure with Filter (iwc)
Outdoor Tonnage
- "Odt" (tons)
Airflow Setting -
"CPC" (CFM/ton)
EXTERNAL STATIC PRESSURE (IN. W. C.)
0.1 0.3 0.5 0.7 0.9
4.0
450
CFM / WATTS 1785 / 339 1788 / 433 1787 / 527 1784 / 623 1778 / 719
420
CFM / WATTS 1670 / 284 1673 / 372 1672 / 460 1669 / 550 1663 / 640
400
CFM / WATTS 1592 / 252 1595 / 335 1594 / 419 1591 / 505 1585 / 592
370
CFM / WATTS 1475 / 207 1477 / 284 1476 / 363 1472 / 443 1466 / 524
350
CFM / WATTS 1396 / 181 1398 / 254 1396 / 329 1392 / 405 1386 / 483
330
CFM / WATTS 1316 / 157 1318 / 226 1315 / 297 1311 / 370 1304 / 444
310
CFM / WATTS 1236 / 135 1237 / 200 1234 / 267 1229 / 337 1222 / 408
290
CFM / WATTS 1155 / 116 1155 / 177 1151 / 240 1146 / 306 1138 / 374
4.5
450
CFM / WATTS 1997 / 459 2000 / 564 1998 / 671 1994 / 777 1988 / 885
420
CFM / WATTS 1870 / 384 1873 / 482 1872 / 582 1869 / 681 1863 / 782
400
CFM / WATTS 1785 / 339 1788 / 433 1787 / 527 1784 / 623 1778 / 719
370
CFM / WATTS 1655 / 278 1658 / 365 1658 / 452 1654 / 541 1648 / 631
350
CFM / WATTS 1568 / 242 1571 / 324 1570 / 407 1566 / 492 1560 / 577
330
CFM / WATTS 1479 / 209 1482 / 286 1481 / 365 1477 / 445 1471 / 527
310
CFM / WATTS 1391 / 179 1393 / 252 1391 / 327 1387 / 403 1381 / 480
290
CFM / WATTS 1301 / 153 1302 / 221 1300 / 291 1296 / 363 1289 / 437
5.0
(a)
450
CFM / WATTS 2204 / 604 2206 / 722 2203 / 840 2198 / 958 2191 / 1077
420
CFM / WATTS 2067 / 504 2069 / 614 2067 / 724 2063 / 835 2056 / 946
400
CFM / WATTS 1974 / 444 1976 / 549 1975 / 653 1971 / 759 1965 / 865
370
CFM / WATTS 1832 / 363 1835 / 460 1835 / 557 1831 / 655 1825 / 754
350
(a)
CFM / WATTS 1737 / 315 1740 / 406 1739 / 498 1736 / 591 1730 / 685
330
CFM / WATTS 1641 / 272 1644 / 358 1643 / 445 1639 / 533 1634 / 622
310
CFM / WATTS 1543 / 232 1546 / 313 1545 / 395 1542 / 478 1536 / 563
290
CFM / WATTS 1445 / 197 1447 / 273 1446 / 350 1442 / 428 1436 / 509
Table 12. S8V2D120M5P Heating Airflow
S8V2D120M5P Furnace Heating Airflow (CFM), Temp. Rise (°F), and Power (Watts) vs. External Static Pressure with
Filter (iwc)
1st Stage Capacity = 67,900
2nd Stage Capacity = 98,000
Heating
Airflow
Setting
Target
Airflow
External Static Pressure
0.1 0.3 0.5 0.7 0.9
Heating 1st
Stage
Low 1155
CFM 1223 1238 1254 1270 1286
Temp. Rise
52 51 51 50 49
Watts 103 173 243 313 384
Medium Low
(a)
1340
CFM 1398 1421 1443 1466 1488
Temp. Rise
44 44 44 43 43
Watts 149 229 310 390 471
Medium 1450
CFM 1496 1510 1525 1540 1555
Temp. Rise
42 41 41 41 41
Watts 181 264 347 430 513
High
1540
CFM 1629 1633 1638 1642 1647
Temp. Rise
39 38 38 38 38
Watts 225 312 398 484 571
Heating 2nd
Stage
Low 1500
CFM 1597 1603 1608 1613 1619
Temp. Rise
56 56 56 55 55
Watts 200 294 388 482 575
Medium Low
(a)
1740
CFM 1822 1832 1843 1854 1865
Temp. Rise
50 49 49 49 48
Watts 296 405 514 624 733
Medium 1850
CFM 1916 1930 1944 1958 1972
Temp. Rise
47 46 46 46 45
Watts 366 484 602 721 839
High
2000
CFM 2045 2064 2082 2101 2120
Temp. Rise
44 44 43 43 42
Watts 463 593 723 854 983
