Trane S8V2D120M5PC User Manual

S8V2-SVX001-1A-EN
21
Table 9. S8V2C080M5P Cooling Airflow
S8V2C080M5P Furnace Cooling Airflow (CFM) and Power (Watts) vs. External Static Pressure with Filter (iwc)
Outdoor Tonnage
- "Odt" (tons)
Airflow Setting -
"CPC" (CFM/ton)
EXTERNAL STATIC PRESSURE (IN. W. C.)
0.1 0.3 0.5 0.7 0.9
2.5
450
CFM / WATTS 1057 / 107 1057 / 168 1055 / 231 1051 / 296 1047 / 363
420
CFM / WATTS 982 / 91 980 / 149 976 / 209 972 / 270 968 / 334
400
CFM / WATTS 932 / 82 928 / 137 924 / 194 919 / 254 914 / 316
370
CFM / WATTS 856 / 69 850 / 121 844 / 174 838 / 231 832 / 290
350
CFM / WATTS 806 / 62 797 / 111 790 / 162 783 / 217 777 / 274
330
CFM / WATTS 755 / 55 744 / 101 735 / 151 728 / 204 721 / 260
310
CFM / WATTS 704 / 48 691 / 92 681 / 140 672 / 191 665 / 246
290
CFM / WATTS 652 / 42 637 / 84 625 / 130 616 / 180 608 / 233
3.0
450
CFM / WATTS 1279 / 164 1284 / 237 1285 / 311 1283 / 387 1280 / 463
420
CFM / WATTS 1190 / 139 1194 / 207 1194 / 277 1192 / 348 1188 / 421
400
CFM / WATTS 1131 / 124 1133 / 189 1132 / 256 1130 / 324 1126 / 394
370
CFM / WATTS 1042 / 104 1041 / 164 1039 / 227 1036 / 291 1032 / 357
350
CFM / WATTS 982 / 91 980 / 149 976 / 209 972 / 270 968 / 334
330
CFM / WATTS 922 / 80 918 / 135 913 / 192 908 / 251 903 / 312
310
CFM / WATTS 861 / 70 855 / 122 849 / 176 843 / 232 838 / 292
290
CFM / WATTS 800 / 61 792 / 110 784 / 161 778 / 215 771 / 273
3.5
450
CFM / WATTS 1498 / 238 1505 / 324 1508 / 410 1507 / 497 1504 / 585
420
CFM / WATTS 1396 / 201 1402 / 281 1404 / 362 1404 / 443 1401 / 525
400
CFM / WATTS 1328 / 179 1333 / 255 1335 / 332 1334 / 410 1331 / 489
370
CFM / WATTS 1225 / 148 1229 / 219 1229 / 290 1227 / 363 1224 / 437
350
CFM / WATTS 1156 / 130 1158 / 197 1158 / 265 1156 / 334 1152 / 405
330
CFM / WATTS 1087 / 114 1087 / 176 1086 / 241 1083 / 307 1079 / 375
310
CFM / WATTS 1017 / 98 1016 / 158 1013 / 219 1009 / 282 1005 / 347
290
CFM / WATTS 947 / 85 944 / 141 939 / 198 935 / 259 930 / 321
4.0
450
CFM / WATTS 1714 / 332 1721 / 431 1724 / 530 1724 / 629 1720 / 728
420
CFM / WATTS 1599 / 279 1607 / 371 1609 / 463 1609 / 556 1606 / 649
400
CFM / WATTS 1522 / 247 1529 / 335 1532 / 422 1532 / 511 1529 / 599
370
CFM / WATTS 1406 / 204 1412 / 285 1414 / 366 1414 / 448 1411 / 531
350
CFM / WATTS 1328 / 179 1333 / 255 1335 / 332 1334 / 410 1331 / 489
330
CFM / WATTS 1250 / 155 1254 / 227 1254 / 300 1253 / 374 1250 / 449
310
CFM / WATTS 1171 / 134 1173 / 201 1173 / 270 1171 / 340 1168 / 412
290
CFM / WATTS 1091 / 115 1092 / 178 1091 / 243 1088 / 309 1084 / 377
4.5
450
CFM / WATTS 1926 / 449 1933 / 561 1935 / 672 1934 / 784 1929 / 895
420
CFM / WATTS 1799 / 376 1807 / 480 1809 / 584 1808 / 688 1805 / 792
400
CFM / WATTS 1714 / 332 1721 / 431 1724 / 530 1724 / 629 1720 / 728
370
CFM / WATTS 1585 / 273 1592 / 364 1595 / 455 1595 / 547 1592 / 639
350
CFM / WATTS 1498 / 238 1505 / 324 1508 / 410 1507 / 497 1504 / 585
330
CFM / WATTS 1411 / 206 1417 / 287 1419 / 368 1418 / 450 1416 / 534
310
CFM / WATTS 1323 / 177 1328 / 253 1330 / 330 1329 / 407 1326 / 486
290
CFM / WATTS 1235 / 151 1239 / 222 1239 / 294 1238 / 367 1234 / 442
5.0
(a)
450
CFM / WATTS 2135 / 590 2140 / 715 2141 / 839 2137 / 964 2131 / 1088
420
CFM / WATTS 1996 / 493 2003 / 609 2004 / 725 2002 / 841 1997 / 956
400
CFM / WATTS 1903 / 435 1910 / 545 1912 / 655 1911 / 765 1906 / 875
370
CFM / WATTS 1761 / 356 1769 / 458 1772 / 559 1771 / 661 1767 / 763
350
(a)
CFM / WATTS 1666 / 310 1674 / 405 1677 / 501 1676 / 501 1673 / 694
330
CFM / WATTS 1570 / 267 1578 / 357 1580 / 448 1580 / 538 1577 / 630
310
CFM / WATTS 1474 / 229 1481 / 313 1483 / 398 1483 / 484 1480 / 570
290
CFM / WATTS 1377 / 194 1383 / 273 1385 / 353 1384 / 433 1381 / 515
AAiirrffllooww TTaabblleess
