Trane TCONT402AN32DA - Fan Control Operation; User Setup Options; Comfort Control Setup Table

Page - 6
Pub. No. 22-5209-01
FAN
- Pressing this key selects whether the indoor fan motor runs in automatic or
continuous mode. The FAN ON indicates that you have selected to operate the fan in continuous mode. Pressing the Fan keypad button again returns the indoor fan mode of operation to automatic and FAN ON goes away.
Fan
Fan
Keypad
Functions
(cont-)
- For variable speed indoor equipment, if you press and hold the Fan button for several seconds, the display changes to the Quick Setup option for continuous fan airflow. Use the UP and DOWN arrow buttons to change the airflow setting. NOTE: This feature is not available if the comfort control is set to BK Output disabled in Installer Setup.
Fan
Page - 19
Pub. No. 22-5209-01
Lock - Unlock Keypad: Press and hold Up Arrow and Down Arrow at the same time for several seconds.
(“Keypad Locked” icon will display on LCD screen)
User
Setup
Options
(cont-)
Menu Item Default
Setting (Choices)
(Press UP or DOWN arrow)
Step
(Press Mode
or Fan)
Temperature Display 0
0 = Fahrenheit
1 = Celsius
50
Auto or Manual
Changeover
1
0 = Manual
1 = Auto
51
Setpoint Deadband 3
2 - 10 Degrees Fahrenheit
1.5 - 5.0 Degrees Celsius
52
Waiting Icon 1
0 = Disable
1 = Enable
53
Cooling Droop 1
0 = Off
1 = 1 Degree
2 = 2 Degrees
54
Energy Savings -
Cooling Setpoint Offset
5
0 - 25 Degrees Fahrenheit 0 - 15 Degrees Celsius
55
Energy Savings - Heating Setpoint Offset
5
0 - 45 Degrees Fahrenheit 0 - 25 Degrees Celsius
56
Indoor Filter Timer Method
0
0 = Calendar Days
1 = Fan Run Time Days
57
Indoor Filter Reminder - Days
30
1 - 180 Days
0 = Disable
58
Menu Item Default
Setting (Choices) (Press UP or DOWN arrow)
Step
(Press Mode
or Fan)
Calibrate Indoor
Temperature
0
Calibrated Room Temperature
+ / - 5 Degrees (1/2 degree
increments)
59
Calibrate Outdoor
Temperature (Enabled
in step 9)
0
Calibrated Outdoor Temperature
+ / - 5 Degrees (1/2 degree
increments)
60
Calibrate Remote
Indoor Temperature
0
Calibrated Room Remote IndoorTemperature + /- 5
Degrees (1/2 degree increments)
61
Continous Fan Airflow 50% 35% - 100% 62
Exit User Setup
(Press Mode)
SA
CA = Cancel
SA = Save
US = Default User Settings
99
(Exit)
Note: Pressing the Energy Saving Key ($) anytime during setup will advance to step 99.
Step 99 - Make setting selection and than press MODE to exit.
SA
ve = Save selections.
US
er = Default User setting.
CAncel = Cancel Selections for current session and return tp previous session selections
Table 1 Comfort Control Setup
