Trane TKD User Manual

18 RT-SVX42B-E4
Appendix
Horizontal flow Plate Heat Exchanger (PHE - H)
50 Pa 150 Pa 250 Pa 350 Pa
Unit size
Airflow
m3/h
absorbed kW Fan speed
Inverter
setting
absorbed kW Fan speed
Inverter
setting
absorbed kW Fan speed
Inverter
setting
absorbed kW Fan speed
Inverter
setting
290-340
1080 n/a n/a n/a n/a n/a n/a 0.3 kW 688 23 Hz 0.5 kW 832 28 Hz
2450 n/a n/a n/a n/a n/a n/a 0.3 kW 746 25 Hz 0.5 kW 875 30 Hz
3820 n/a n/a n/a 0.3 kW 654 22 Hz 0.4 kW 817 28 Hz 0.6 kW 931 32 Hz
5190 0.4 kW 596 20 Hz 0.4 kW 765 26 Hz 0.5 kW 900 31 Hz 0.8 kW 1000 34 Hz
6560 0.4 kW 748 26 Hz 0.6 kW 879 30 Hz 0.8 kW 990 34 Hz 1.0 kW 1080 37 Hz
7930 0.6 kW 897 31 Hz 0.8 kW 998 34 Hz 1.1 kW 1089 37 Hz 1.4 kW 1171 40 Hz
9300 0.8 kW 1042 36 Hz 1.1 kW 1119 38 Hz 1.4 kW 1196 41 Hz 1.8 kW 1273 43 Hz
10670 1.2 kW 1185 40 Hz 1.6 kW 1244 42 Hz 1.9 kW 1311 45 Hz 2.2 kW 1384 47 Hz
12040 1.7 kW 1328 45 Hz 2.1 kW 1374 47 Hz 2.5 kW 1434 49 Hz 2.8 kW 1506 51 Hz
13410 2.2 kW 1472 50 Hz 2.7 kW 1510 52 Hz 3.1 kW 1564 53 Hz 3.5 kW 1635 56 Hz
14780 2.9 kW 1618 55 Hz 3.4 kW 1650 56 Hz 3.9 kW 1700 58 Hz 4.3 kW 1769 60 Hz
16150 3.7 kW 1768 60 Hz 4.3 kW 1794 61 Hz 4.8 kW 1839 63 Hz 5.2 kW 1902 65 Hz
17520 4.7 kW 1921 66 Hz 5.3 kW 1940 66 Hz 5.8 kW 1975 67 Hz 6.3 kW 2026 69 Hz
18890 5.7 kW 2074 71 Hz 6.4 kW 2081 71 Hz n/a n/a n/a n/a n/a n/a
20260 n/a n/a n/a n/a n/a n/a n/a n/a n/a n/a n/a n/a
21600 n/a n/a n/a n/a n/a n/a n/a n/a n/a n/a n/a n/a
Horizontal flow Plate Heat Exchanger (PHE - H)
50 Pa 150 Pa 250 Pa 350 Pa
Unit size
Airflow
m3/h
absorbed kW Fan speed
Inverter
setting
absorbed kW Fan speed
Inverter
setting
absorbed kW Fan speed
Inverter
setting
absorbed kW Fan speed
Inverter
setting
275-300-
350
1020 n/a n/a n/a n/a n/a n/a 0.3 kW 691 24 Hz 0.5 kW 819 28 Hz
2310 n/a n/a n/a 0.3 kW 563 19 Hz 0.3 kW 742 25 Hz 0.6 kW 861 29 Hz
3600 n/a n/a n/a 0.3 kW 653 22 Hz 0.4 kW 808 28 Hz 0.6 kW 915 31 Hz
4890 0.3 kW 586 20 Hz 0.4 kW 752 26 Hz 0.5 kW 884 30 Hz 0.8 kW 981 33 Hz
6180 0.4 kW 721 25 Hz 0.5 kW 856 29 Hz 0.7 kW 968 33 Hz 1.0 kW 1056 36 Hz
7470 0.5 kW 857 29 Hz 0.7 kW 966 33 Hz 1.0 kW 1061 36 Hz 1.3 kW 1142 39 Hz
8760 0.8 kW 992 34 Hz 1.0 kW 1079 37 Hz 1.3 kW 1161 40 Hz 1.6 kW 1237 42 Hz
10050 1.1 kW 1127 38 Hz 1.4 kW 1196 41 Hz 1.7 kW 1268 43 Hz 2.1 kW 1341 46 Hz
11340 1.5 kW 1262 43 Hz 1.9 kW 1318 45 Hz 2.2 kW 1382 47 Hz 2.6 kW 1454 50 Hz
12630 2.0 kW 1398 48 Hz 2.4 kW 1445 49 Hz 2.8 kW 1503 51 Hz 3.2 kW 1575 54 Hz
13920 2.6 kW 1536 52 Hz 3.1 kW 1575 54 Hz 3.5 kW 1630 56 Hz 3.9 kW 1701 58 Hz
15210 3.3 kW 1675 57 Hz 3.8 kW 1708 58 Hz 4.3 kW 1760 60 Hz 4.7 kW 1829 62 Hz
16500 4.1 kW 1816 62 Hz 4.7 kW 1843 63 Hz 5.2 kW 1890 64 Hz 5.6 kW 1954 67 Hz
17790 5.1 kW 1957 67 Hz 5.7 kW 1977 67 Hz 6.3 kW 2015 69 Hz 6.8 kW 2072 71 Hz
19080 6.2 kW 2094 71 Hz n/a n/a n/a n/a n/a n/a n/a n/a n/a
20400 n/a n/a n/a n/a n/a n/a n/a n/a n/a n/a n/a n/a
Horizontal flow Plate Heat Exchanger (PHE - H)
50 Pa 150 Pa 250 Pa 350 Pa
Unit size
Airflow
m3/h
absorbed kW Fan speed
Inverter
setting
absorbed kW Fan speed
Inverter
setting
absorbed kW Fan speed
Inverter
setting
absorbed kW Fan speed
Inverter
setting
400-500-
600
1620 n/a n/a n/a n/a n/a n/a n/a n/a n/a 0.9 kW 640 22 Hz
3680 n/a n/a n/a 0.4 kW 442 15 Hz 0.5 kW 584 20 Hz 0.9 kW 678 23 Hz
5740 n/a n/a n/a 0.5 kW 517 18 Hz 0.6 kW 640 22 Hz 1.0 kW 725 25 Hz
7800 0.5 kW 467 16 Hz 0.6 kW 599 20 Hz 0.8 kW 703 24 Hz 1.3 kW 780 26 Hz
9860 0.6 kW 575 19 Hz 0.8 kW 683 23 Hz 1.1 kW 772 26 Hz 1.6 kW 841 29 Hz
11920 0.9 kW 684 23 Hz 1.1 kW 771 26 Hz 1.5 kW 847 29 Hz 2.0 kW 911 31 Hz
13980 1.2 kW 791 27 Hz 1.6 kW 861 29 Hz 2.1 kW 927 31 Hz 2.6 kW 987 33 Hz
16040 1.7 kW 897 30 Hz 2.2 kW 954 32 Hz 2.7 kW 1012 34 Hz 3.3 kW 1070 36 Hz
18100 2.4 kW 1003 34 Hz 3.0 kW 1050 36 Hz 3.5 kW 1102 37 Hz 4.1 kW 1160 39 Hz
20160 3.2 kW 1109 38 Hz 3.9 kW 1149 39 Hz 4.5 kW 1198 41 Hz 5.0 kW 1256 43 Hz
22220 4.2 kW 1216 41 Hz 4.9 kW 1251 42 Hz 5.6 kW 1298 44 Hz 6.1 kW 1358 46 Hz
24280 5.4 kW 1324 45 Hz 6.2 kW 1356 46 Hz 6.8 kW 1403 48 Hz 7.4 kW 1463 50 Hz
26340 6.7 kW 1435 49 Hz 7.6 kW 1464 50 Hz 8.3 kW 1509 51 Hz 8.9 kW 1570 53 Hz
28400 8.3 kW 1546 52 Hz 9.2 kW 1573 53 Hz 10.0 kW 1616 55 Hz 10.6 kW 1675 57 Hz
30460 10.1 kW 1657 56 Hz 11.1 kW 1681 57 Hz 11.9 kW 1719 58 Hz 12.6 kW 1773 60 Hz
32450 12.1 kW 1762 60 Hz 13.1 kW 1779 60 Hz n/a n/a n/a n/a n/a n/a
