Table 3 - Exhaust fan performances
Downflow Energy Recovery Wheel (ERW - D)
50 Pa 150 Pa 250 Pa 350 Pa
Unit size
Airflow
m3/h
absorbed kW Fan speed
Inverter
setting
absorbed kW Fan speed
Inverter
setting
absorbed kW Fan speed
Inverter
setting
absorbed kW Fan speed
Inverter
setting
125-155-
175
590 n/a n/a n/a n/a n/a n/a n/a n/a n/a 0.3 kW 1177 20 Hz
1340 n/a n/a n/a n/a n/a n/a 0.2 kW 1085 19 Hz 0.3 kW 1257 22 Hz
2090 n/a n/a n/a 0.2 kW 988 17 Hz 0.2 kW 1208 21 Hz 0.3 kW 1353 23 Hz
2840 0.2 kW 940 16 Hz 0.2 kW 1166 20 Hz 0.3 kW 1341 23 Hz 0.5 kW 1466 25 Hz
3590 0.3 kW 1168 20 Hz 0.3 kW 1340 23 Hz 0.5 kW 1481 25 Hz 0.6 kW 1592 27 Hz
4340 0.4 kW 1388 24 Hz 0.5 kW 1516 26 Hz 0.6 kW 1633 28 Hz 0.8 kW 1736 30 Hz
5090 0.5 kW 1599 27 Hz 0.7 kW 1697 29 Hz 0.9 kW 1796 31 Hz 1.0 kW 1896 33 Hz
5840 0.8 kW 1807 31 Hz 1.0 kW 1882 32 Hz 1.2 kW 1970 34 Hz 1.3 kW 2070 36 Hz
6590 1.1 kW 2016 35 Hz 1.3 kW 2076 36 Hz 1.5 kW 2157 37 Hz 1.7 kW 2257 39 Hz
7340 1.4 kW 2229 38 Hz 1.7 kW 2280 39 Hz 1.9 kW 2354 40 Hz 2.1 kW 2452 42 Hz
8090 1.8 kW 2450 42 Hz 2.1 kW 2493 43 Hz 2.3 kW 2560 44 Hz 2.5 kW 2651 46 Hz
8840 2.3 kW 2679 46 Hz 2.6 kW 2713 47 Hz 2.8 kW 2769 48 Hz 3.1 kW 2846 49 Hz
9590 2.8 kW 2917 50 Hz 3.1 kW 2938 50 Hz 3.4 kW 2974 51 Hz n/a n/a n/a
10340 n/a n/a n/a n/a n/a n/a n/a n/a n/a n/a n/a n/a
11090 n/a n/a n/a n/a n/a n/a n/a n/a n/a n/a n/a n/a
11820 n/a n/a n/a n/a n/a n/a n/a n/a n/a n/a n/a n/a
Downflow Energy Recovery Wheel (ERW - D)
50 Pa 150 Pa 250 Pa 350 Pa
Unit size
Airflow
m3/h
absorbed kW Fan speed
Inverter
setting
absorbed kW Fan speed
Inverter
setting
absorbed kW Fan speed
Inverter
setting
absorbed kW Fan speed
Inverter
setting
200-250-
265
850 n/a n/a n/a n/a n/a n/a 0.2 kW 785 27 Hz 0.4 kW 927 32 Hz
1920 n/a n/a n/a 0.2 kW 662 23 Hz 0.3 kW 851 29 Hz 0.5 kW 979 33 Hz
2990 0.3 kW 555 19 Hz 0.3 kW 766 26 Hz 0.3 kW 929 32 Hz 0.5 kW 1043 36 Hz
4060 0.3 kW 702 24 Hz 0.3 kW 877 30 Hz 0.5 kW 1016 35 Hz 0.7 kW 1119 38 Hz
5130 0.4 kW 848 29 Hz 0.5 kW 992 34 Hz 0.7 kW 1111 38 Hz 0.9 kW 1205 41 Hz
6200 0.5 kW 996 34 Hz 0.7 kW 1113 38 Hz 0.9 kW 1216 41 Hz 1.1 kW 1303 44 Hz
7270 0.7 kW 1144 39 Hz 0.9 kW 1240 42 Hz 1.2 kW 1328 45 Hz 1.4 kW 1411 48 Hz
8340 1.0 kW 1294 44 Hz 1.3 kW 1371 47 Hz 1.5 kW 1448 49 Hz 1.8 kW 1527 52 Hz
9410 1.3 kW 1445 49 Hz 1.7 kW 1507 51 Hz 2.0 kW 1575 54 Hz 2.3 kW 1651 56 Hz
10480 1.7 kW 1599 54 Hz 2.1 kW 1648 56 Hz 2.4 kW 1708 58 Hz 2.8 kW 1781 61 Hz
11550 2.2 kW 1756 60 Hz 2.6 kW 1794 61 Hz 3.0 kW 1846 63 Hz 3.3 kW 1915 65 Hz
12620 2.8 kW 1916 65 Hz 3.2 kW 1943 66 Hz 3.7 kW 1988 68 Hz 4.0 kW 2051 70 Hz
13690 3.4 kW 2078 71 Hz 3.9 kW 2093 71 Hz 4.4 kW 2128 73 Hz 4.8 kW 2183 74 Hz
14760 n/a n/a n/a n/a n/a n/a n/a n/a n/a n/a n/a n/a
15830 n/a n/a n/a n/a n/a n/a n/a n/a n/a n/a n/a n/a
16920 n/a n/a n/a n/a n/a n/a n/a n/a n/a n/a n/a n/a
