Trane TSC037E User Manual

62 RT-SVX22M-EN
Unit Wiring Diagrams Numbers
Note: Wiring diagrams can be accessed using e-Library
by entering the diagram number in the literature
order number search field or by contacting
technical support.
Table 16. Unit wiring diagram numbers
Schematic Type Drawing Number Description
Control
Reliatel™
230,460,575V
4366-7216 THC(037-067)
4366-4568 T(S,H)C(036-060)E/F(1,3,4), ReliaTel Controls, X13 IDM
4366-1026
T(S,H)C(036-090)E/F(3,4,W), ReliaTel Controls,
Belt-Drive IDM
4366-1044 TSC(092,102)F(3,4,W), ReliaTel Controls
4366-7433 THC(092-102)F(3,4),TSC120F(3,4,W), ReliaTel Controls
4366-7426 THC120E(3,4), ReliaTel Controls
Electromechanical
4366-8350
T(S,H)C(036-060)E,F(1,3,4), Electromechanical Controls,
X13 IDM
4366-8348
T(S,H)C(036-060)E,F(3,4,W), Electromechanical Controls,
Belt-Drive IDM
4366-8347 T(S,H)C(072,090)F(3,4,W), Electromechanical Controls
4366-8349 TSC(092,102)F(3,4,W), Electromechanical Controls
4366-8352
THC(092-102)F(3,4),TSC120F(3,4,W), Electromechanical
Controls
4366-8351 THC120E(3,4), Electromechanical Controls
Schematic Type Drawing Number Description
Power
Reliatel
230V
4366-7177 THC(037-067) (230V)
4366-4574 T(S,H)C(036-060)E,F (1-Phase)
4366-5161 THC(036-060)E,F (3-Phase), X13 IDM
4366-1037 TSC(092,102)F
4366-7431 (THC092-102, TSC120)F (230V), ReliaTel Controls
4366-7426 THC120E, ReliaTel Controls
460V and/or
575V
4366-7178 THC(037-067) (460V)
4366-5161 THC(036-060)E,F (3-Phase), X13 IDM
4366-1037 TSC(092,102)F
4366-7431 (THC092-102, TSC120)F (460V), ReliaTel Controls
4366-7434 TSC120F (575V), ReliaTel Controls
4366-7426 THC120E, ReliaTel Controls
Electromechanical
230V
4366-6428 THC(092-120)E, Electromechanical Controls
4366-6433 THC(092-102)F, TSC120, Electromechanical Controls
460V and/or
575V
4366-6428 THC120E, Electromechanical Controls
4366-6433 THC(092-102)F4,TSC(120)F4, Electromechanical Controls
4366-6781 TSC120FW, Electromechanical Controls
