Trane TTK 509 E - Wiring Interconnection - MCD Models; Single Power Supply; Separate Power Supply

SS-SVN03B-EN 17
Wiring
Interconnection
Figure 16. Wiring Interconnection: MCD with condensing units TTK
Figure 17. Wiring Interconnection: MCD with condensing units TTK
NOTES:
1) Single power supply point for each unit.
(indoor unit and outdoor unit)
NOTES:
1) Single power supply point for both units.
(indoor unit and outdoor unit)
208-230V 1PH
50/60 Hz
208-230V 1PH
50/60 Hz
208-230V 1PH
50/60 Hz
