12
PUB. NO. 22-1802-03
Performance
Data
SW7 SW8 0.1 0.3 0.5 0.7 0.9
CFM 1003 1039 1062 1033 1034
Temp. Rise 58 56 54 56 56
Watts 125 182 246 309 356
CFM 1137 1193 1185 1197 1185
Temp. Rise 51 48 49 48 49
Watts 170 239 293 370 446
CFM 1262 1290 1327 1344 1331
Temp. Rise 46 45 44 43 43
Watts 218 286 366 440 534
CFM 1415 1454 1476 1500 1421
Temp. Rise 63 61 60 59 63
Watts 297 378 453 534 561
CFM 1645 1672 1701 1659 1456
Temp. Rise 54 53 52 54 61
Watts 435 539 632 671 580
CFM 1834 1857 1837 1686 1506
Temp. Rise 48 48 48 53 59
Watts 608 705 778 699 630
OFF
Medium** ON
Airflow
Setting
Dip Switch Setting External Static Pressure
Low
High
Low
Medium**
ON
ON
ON
High
Heating
Heating
1st Stage
Heating
2nd
Stage
OFF
OFF
ON ON
OFF
*UD2D120AFV52A Furnace Heating Airflow (CFM) and Power (watts) vs. External Static Pressure With Filter
OFF
OFF
SW1 SW2 SW3 SW4 0.1 0.3 0.5 0.7 0.9
CFM
1141 1197 1205 1196 1188
Watts
170 246 299 369 443
CFM
1325 1374 1403 1434 1412
Watts
252 332 408 496 567
CFM
1536 1575 1615 1619 1474
Watts
370 464 563 640 605
CFM
1334 1376 1424 1411 1417
Watts
251 330 415 469 562
CFM
1582 1628 1659 1663 1465
Watts
387 491 595 672 595
CFM
1813 1836 1838 1707 1504
Watts
577 684 771 710 620
CFM
1704 1731 1733 1735 1552
Watts
489 589 666 750 663
CFM
1960 1971 1937 1799 1602
Watts
739 841 891 813 700
CFM
2208 2107 1970 1849 1683
Watts
1080 1025 942 863 776
Notes:
1. * First letter may be "A" or "T".
2. ** Factory setting.
3. Continuous Fan Setting: Heating or cooling airflow is approximately 50% of selected cooling value.
4. For variable speed low speed airflows are approximately 30% of listed values.
5. LOW 350 cfm/ton is recommended for variable speed application for COMFORT & HUMID CLIMATE setting; NORMAL is 400 cfm/ton;
HIGH 450 cfm/ton is for DRY CLIMATE setting.
Cooling
ON
ON
OFF
ON
OFF
OFF
OFF
*UD2D120AFV52A Furnace Cooling Airflow (CFM) and Power (Watts) vs. External Static Pressure With Filter
External Static Pressure
OFF
ONOFFON
OFF ON
OFF
OFF
OFF
ONON
ON
OFFOFFOFF
OFF OFF
OFFONOFF
5**
OFF OFF
High (450
CFM/ton)
ONOFFOFF
4
3.5
Low (350
CFM/Ton)
Normal (400
CFM/ton)
High (450
CFM/ton)
ON OFF
Airflow
Setting
Normal (400
CFM/ton)
Low (350
CFM/Ton)
Normal (400
CFM/ton)
High (450
CFM/ton)
Dip Switch Setting
OFF
OFF
Unit
Outdoor
Low (350
CFM/Ton)
