Trane TWA Series Application Guide

20 SS-APG008-EN Parts
Parts
Table 2. TTA component selection summary
UNIT TTA073D TTA090D TTA120D TTA120E TTA120F TTA150E TTA180E TTA180F TTA240E TTA240F
Refrigerant ckts 11121 (Manifold) 2 21 (Manifold)21 (Manifold)
Minimum step (tons)
67.510 5 56.257.5 7.5 10 10
GAS LINE GAS LINE
Tube diameter (in.)
Horizontal (& drops) 1 1/8 1 3/8 1 3/8 1 1/8 1 3/8 1 1/8 1 3/8 1 5/8 1 3/8 1 5/8
Vertical (up)
1 1/8 1 3/8 1 3/8 1 1/8 1 1/8 1 1/8 1 3/8 1 3/8 1 3/8 1 5/8
Access port 3/ckt
Schraeder
valve w/core*
Schraeder
valve w/core*
Schraeder
valve w/core*
Schraeder
valve w/core*
Schraeder
valve w/core*
Schraeder
valve w/core*
Schraeder
valve w/core*
Schraeder
valve w/core*
Schraeder
valve w/core*
Schraeder
valve w/core*
LIQUID LINE LIQUID LINE
Tube diameter (in.) 1/2 5/8 1/2 1/2 1/2 1/2 1/2 5/8 1/2 5/8
Filter drier
DHY01123** DHY01232** DHY01123** DHY01123** DHY01123** DHY01123** DHY01123** DHY01131** DHY01123** DHY01132**
Sight glass 1/ckt
GLS00853 GLS00830 GLS00853 GLS00853 GLS00853 GLS00853 GLS00853 GLS00830 GLS00853 GLS00830
Access port 2/ckt
Schraeder
valve w/core*
Schraeder
valve w/core*
Schraeder
valve w/core*
Schraeder
valve w/core*
Schraeder
valve w/core*
Schraeder
valve w/core*
Schraeder
valve w/core*
Schraeder
valve w/core*
Schraeder
valve w/core*
Schraeder
valve w/core*
Check valve selections (see “Check Valves,” p. 6)
3/8 - VAL08459
1/2 - VAL08460
5/8 - VAL01722
* Valve body VAL01483, valve core COR00006, valve cap CAP00072
** For units with line lengths in excess of 80 ft, the included filter must be removed and a filter from the table must be installed close to the air handler. See “Liquid Filter Drier,” p. 5.
