Trane TWA Series User Manual

8 TWA-SVX01A-EN
Table 1 - TWA Unit Electrical Data
Basic Unit Characteristics Compressor Motor Outdoor Fan Motor
Allowable Minimum
M
aximum
Model Electrical Voltage Circuit Fuse Amps Amps
Number Characteristics Range Ampacity Size Qty. RLA LRA Qty. HP FLA LRA
TWA090A3 208-230/60/3 187-254 34.5 50 1 25.1 182.0 1 1/2 3.1 8.1
TWA090A4 460/60/3 414-506 18.1 25 1 13.2 94.9 1 1/2 1.6 3.7
TWA090AW 575/60/3 518-632 14.5 20 1 10.6 70.0 1 1/2 1.2 3.0
TWA075AD 380-415/50/3 380-415 12.6 20 1 8.8 90.0 1 1/2 1.6 3.7
TWA120A3 208-230/60/3 187-254 48.1 70 1 33.7 278.0 1 1 6.0 17.5
TWA120A4 460/60/3 414-506 23.3 35 1 16.5 124.0 1 1 2.7 7.0
TWA120AW 575/60/3 518-632 18.8 25 1 13.4 92.0 1 1 2.0 5.7
TWA100AD 380-415/50/3 380-415 22.5 35 1 15.8 124.0 1 1 2.7 7.0
TWA180B3 208-230/60/3 187-254 62.7 80 2 25.1 182.0 2 1/2 3.1 8.1
TWA180B4 460/60/3 414-506 32.9 45 2 13.2 94.9 2 1/2 1.6 3.7
TWA180BW 575/60/3 518-632 26.3 35 2 10.6 70.0 2 1/2 1.2 3.0
TWA155BD 380-415/50/3 380-415 28.4 35 2 11.2 94.9 2 1/2 1.6 3.7
TWA240B3 208-230/60/3 187-254 87.8 100 2 33.7 278.0 2 1 6.0 17.5
TWA240B4 460/60/3 414-506 42.5 50 2 16.5 120.0 2 1 2.7 7.0
TWA240BW 575/60/3 518-632 34.2 45 2 13.4 92.0 2 1 2.0 5.7
TWA200BD 380-415/50/3 380-415 41.0 50 2 15.8 124.0 2 1 2.7 7.0
Electrical Data
