TWE5-PRC001-EN-10-15-99 15
TWA040CD WITH TWE050CA5-C AT 2547 CMH (CAPACITIES ARE GROSS IN KILOWATTS-INDOOR FAN HEAT IGNORED)
O.D. I.D. TOTAL SENS. CAP. AT ENTERING D.B. TEMP. COMPR.
D.B. W.B. CAP. 22.2 23.3 24.4 25.6 26.7 KW
15.0 11.7 9.7 10.5 11.3 11.9* 12.2* 2.8
29.4 17.2 12.6 8.2 9.0 9.8 10.5 11.3 2.9
19.4 13.5 6.5 7.3 8.1 8.8 9.6 3.0
21.7 14.4 4.8 5.5 6.3 7.1 7.9 3.1
15.0 11.5 9.6 10.4 11.2 11.7* 11.9* 2.9
32.2 17.2 12.3 8.1 8.8 9.6 10.4 11.2 3.0
19.4 13.2 6.4 7.1 7.9 8.7 9.5 3.1
21.7 14.1 4.6 5.4 6.2 7.0 7.8 3.3
15.0 11.2 9.5 10.3 11.0 11.4* 11.7* 3.0
35.0 17.2 12.0 7.9 8.7 9.5 10.3 11.1 3.2
19.4 12.8 6.2 7.0 7.8 8.6 9.4 3.3
21.7 13.7 4.5 5.3 6.1 6.9 7.6 3.4
15.0 10.8 9.3 10.1 10.9* 11.1* 11.4* 3.2
37.8 17.2 11.6 7.8 8.6 9.4 10.1 10.9 3.3
19.4 12.5 6.1 6.9 7.7 8.4 9.2 3.4
21.7 13.3 4.4 5.2 5.9 6.7 7.5 3.5
15.0 10.5 9.2 10.0 10.6* 10.9* 11.1* 3.3
40.6 17.2 11.3 7.6 8.4 9.2 10.0 10.8 3.4
19.4 12.1 5.9 6.7 7.5 8.3 9.1 3.5
21.7 12.9 4.2 5.0 5.8 6.6 7.4 3.7
15.0 9.8 8.9 9.7 10.1* 10.3* 10.5* 3.6
46.1 17.2 10.6 7.4 8.2 9.0 9.7 10.5 3.7
19.4 11.3 5.7 6.5 7.2 8.0 8.8 3.8
21.7 12.1 4.0 4.7 5.5 6.3 7.1 4.0
TWA050CD WITH TWE050CA5-C AT 3057 CMH (CAPACITIES ARE GROSS IN KILOWATTS-INDOOR FAN HEAT IGNORED)
O.D. I.D. TOTAL SENS. CAP. AT ENTERING D.B. TEMP. COMPR.
D.B. W.B. CAP. 22.2 23.3 24.4 25.6 26.7 KW
15.0 14.3 11.6 12.5 13.4 14.4* 14.7* 3.6
29.4 17.2 15.3 9.8 10.7 11.6 12.5 13.4 3.7
19.4 16.4 7.8 8.7 9.6 10.5 11.4 3.8
21.7 17.5 5.7 6.7 7.6 8.5 9.4 4.0
15.0 13.9 11.5 12.4 13.3 14.1* 14.4* 3.8
32.2 17.2 14.9 9.6 10.5 11.5 12.4 13.3 3.9
19.4 16.0 7.6 8.6 9.5 10.4 11.3 4.0
21.7 17.0 5.6 6.5 7.4 8.3 9.2 4.1
15.0 13.6 11.3 12.2 13.1 13.8* 14.1* 3.9
35.0 17.2 14.6 9.5 10.4 11.3 12.2 13.1 4.1
19.4 15.6 7.5 8.4 9.3 10.2 11.1 4.2
21.7 16.6 5.4 6.4 7.3 8.2 9.1 4.3
15.0 13.2 11.1 12.0 13.0 13.4* 13.7* 4.1
37.8 17.2 14.1 9.3 10.2 11.1 12.0 13.0 4.2
19.4 15.1 7.3 8.2 9.1 10.0 11.0 4.3
21.7 16.1 5.3 6.2 7.1 8.0 8.9 4.5
15.0 12.8 11.0 11.9 12.8 13.1* 13.4* 4.3
40.6 17.2 13.7 9.1 10.0 11.0 11.9 12.8 4.4
19.4 14.6 7.1 8.1 9.0 9.9 10.8 4.5
21.7 15.6 5.1 6.0 6.9 7.9 8.8 4.6
15.0 12.0 10.6 11.5 12.2* 12.5* 12.7* 4.6
46.1 17.2 12.9 8.8 9.7 10.6 11.5 12.5 4.7
19.4 13.7 6.8 7.7 8.6 9.6 10.5 4.8
21.7 14.6 4.8 5.7 6.6 7.5 8.4 4.9
Performance
Data Cooling Metric Units
CORRECTION FACTORS - OTHER AIRFLOWS
(MULTIPLY OR ADD AS INDICATED)
AIRFLOW 2250 2887
TOTAL CAP. X0.99 X1.01
SENS. CAP. X0.95 X1.06
COMPR. KW X0.99 X1.01
VALUES AT ARI RATING CONDITIONS
GROSS CAPACITY = 12.83 KW
AIRFLOW = 2547 CMH
COMPRESSOR POWER = 3279 WATTS
I.D. FAN POWER = 510 WATTS
O.D. FAN POWER = 244 WATTS
E.E.R. = 10.30 BTUH/WATT
NOTE:RATED WITH 7.62 METERS OF 28.6 MM SUCT.
AND 9.5 MM LIQUID LINES
* DRY COIL CONDITION (TOTAL CAPACITY =
SENSIBLE CAPACITY)
TOTAL CAPACITY, COMP. KW AND APP. DEW PT.
ARE VALID ONLY FOR WET COIL
ALL TEMPERATURES IN DEGREES C.
CORRECTION FACTORS - OTHER AIRFLOWS
(MULTIPLY OR ADD AS INDICATED)
AIRFLOW 2675 3439
TOTAL CAP. X0.99 X1.01
SENS. CAP. X0.95 X1.05
COMPR. KW X0.99 X1.01
VALUES AT ARI RATING CONDITIONS
GROSS CAPACITY = 15.56 KW
AIRFLOW = 3057 CMH
COMPRESSOR POWER = 4171 WATTS
I.D. FAN POWER = 750 WATTS
O.D. FAN POWER = 255 WATTS
E.E.R. = 9.65 BTUH/WATT
NOTE:RATED WITH 7.62 METERS OF 28.6 MM SUCT.
AND 9.5 MM LIQUID LINES
* DRY COIL CONDITION (TOTAL CAPACITY =
SENSIBLE CAPACITY)
TOTAL CAPACITY, COMP. KW AND APP. DEW PT.
ARE VALID ONLY FOR WET COIL
ALL TEMPERATURES IN DEGREES C.
TWA060CD WITH TWE050CA5-C AT 3057 CMH (CAPACITIES ARE GROSS IN KILOWATTS-INDOOR FAN HEAT IGNORED)
O.D. I.D. TOTAL SENS. CAP. AT ENTERING D.B. TEMP. COMPR.
D.B. W.B. CAP. 22.2 23.3 24.4 25.6 26.7 KW
15.0 16.8 12.8 13.7 14.6 15.6 16.5 4.6
29.4 17.2 18.0 11.0 11.9 12.9 13.8 14.7 4.8
19.4 19.4 9.0 10.0 10.9 11.8 12.7 4.9
21.7 20.7 7.0 7.9 8.8 9.8 10.7 5.1
15.0 16.4 12.6 13.6 14.5 15.4 16.3 4.8
32.2 17.2 17.6 10.8 11.8 12.7 13.6 14.5 5.0
19.4 18.9 8.8 9.8 10.7 11.6 12.5 5.1
21.7 20.2 6.8 7.7 8.6 9.6 10.5 5.3
15.0 16.0 12.5 13.4 14.3 15.2 16.1* 5.0
35.0 17.2 17.2 10.7 11.6 12.5 13.4 14.4 5.2
19.4 18.5 8.7 9.6 10.5 11.5 12.4 5.3
21.7 19.8 6.7 7.6 8.5 9.4 10.3 5.5
15.0 15.6 12.3 13.2 14.1 15.1 15.8* 5.2
37.8 17.2 16.8 10.5 11.4 12.3 13.2 14.2 5.4
19.4 18.0 8.5 9.4 10.3 11.3 12.2 5.6
21.7 19.3 6.4 7.4 8.3 9.2 10.1 5.7
15.0 15.2 12.1 13.0 13.9 14.9 15.4* 5.4
40.6 17.2 16.3 10.3 11.2 12.2 13.1 14.0 5.6
19.4 17.5 8.3 9.2 10.2 11.1 12.0 5.8
21.7 18.8 6.3 7.2 8.1 9.0 10.0 5.9
15.0 14.3 11.7 12.7 13.6 14.4* 14.8* 5.9
46.1 17.2 15.4 9.9 10.9 11.8 12.7 13.6 6.1
19.4 16.6 7.9 8.8 9.8 10.7 11.6 6.2
21.7 17.7 5.9 6.8 7.7 8.7 9.6 6.4
CORRECTION FACTORS - OTHER AIRFLOWS
(MULTIPLY OR ADD AS INDICATED)
AIRFLOW 2675 3439
TOTAL CAP. X0.98 X1.01
SENS. CAP. X0.95 X1.05
COMPR. KW X0.99 X1.01
VALUES AT ARI RATING CONDITIONS
GROSS CAPACITY = 18.49 KW
AIRFLOW = 3057 CMH
COMPRESSOR POWER = 5326 WATTS
I.D. FAN POWER = 750 WATTS
O.D. FAN POWER = 395 WATTS
E.E.R. = 9.20 BTUH/WATT
NOTE:RATED WITH 7.62 METERS OF 28.6 MM SUCT.
AND 9.5 MM LIQUID LINES
* DRY COIL CONDITION (TOTAL CAPACITY =
SENSIBLE CAPACITY)
TOTAL CAPACITY, COMP. KW AND APP. DEW PT. ARE
VALID ONLY FOR WET COIL
ALL TEMPERATURES IN DEGREES C.
