General
Data TWE
TWE Product Specifications
Model TWE030CA40B TWE040CA40C TWE050CA50D
Power Conn.— Volts/Ph/Hz 220/1/50 220/1/50 220/1/50
Indoor Coil - Type Plate Fin Plate Fin Plate Fin
Rows 3 3 3
Fins per inch (Fins per 25.4 mm) 14 14 14
Face Area sq ft (sq m) 3.21 (.30) 5.04 (.47) 6.19 (.58)
Tube Size in. (mm) 3/8 (9.52) 3/8 (9.52) 3/8 (9.52)
Refrigerant Control FCCV FCCV FCCV
Drain Conn. Size in. (mm) 3/4 NPT 3/4 NPT 3/4 NPT
Duct Connections See Outline Drawing See Outline Drawing See Outline Drawing
Indoor Fan - Type Centrifugal Centrifugal Centrifugal
No. Used 1 1 1
Diameter in. (mm) 10.0 (254.0) 10.0 (254.0) 11.0 (279.4)
Width in. (mm) 8.0 (203.2) 10.0 (254.0) 10.0 (254.0)
Type Drive - No. Speeds Direct - 3 Direct - 3 Direct - 3
Airflow (High)
CFM @ 0.0 in. w.g. See Fan Performance Table See Fan Performance Table See Fan Performance Table
CMH @ 0.0 Pa See Fan Performance Table See Fan Performance Table See Fan Performance Table
No. Motors - HP 1 - 1/3 1 - 1/3 1 - 3/4
Motor RPM 1000 900 900
Volts/Ph/Hz 220/1/50 220/1/50 220/1/50
F.L. Amps 2.6 2.1 4.5
L.R. Amps 3.3 4.2 10.1
Filters
Vertical Applications
Filter Furnished Yes Yes Yes
Type Furnished Throwaway Throwaway High Velocity
No.-Size-Thickness 1 - 20 x 20 - 1 1 - 20 x 20 - 1 1 - 2 2 x 20 - 1
Horizontal Applications
Filter Furnished No No No
Type Recommended See Note Below See Note Below See Note Below
No.-Size-Thickness See Note Below See Note Below See Note Below
Refrigerant Line Size
Line Size ID Gas in. (mm) 7/8 (22.23) 1-1/8 (28.56) 1-1/8 (28.56)
Line Size ID Liquid in. (mm) 3/8 (9.52) 3/8 (9.52) 3/8 (9.52)
Dimensions (H x W x D)
Crated- in. 44.5 x 24.0 x 23.5 53.25 x 26.0 x 23.5 59.5 x 26.0 x 23.5
- (mm) (1130 x 610 x 597) (1353 x 660 x 597) (1511 x 660 x 597)
Uncrated - in. 43.0 x 21.5 x 21.0 52.0 x 23.5 x 21.0 58.0 x 23.5 x 21.0
- (mm) (1092 x 546 x 533) (1321 x 597x 533) (1473 x 597 x 533)
Weight Ibs. (kg)
Shipping 125 (56.7) 165 (74.8) 198 (898)
Net 115 (52.2) 150 (68.0) 183 (83.0)
Minimum filter size for horizontal applications based on airflow selection and calculated as follows:
Low Velocity Filter: Face Area (sq ft) = CFM/300
High Velocity Filter: Face Area (sq ft) = CFM/500
