8 TWE5-PRC001-EN-10-15-99
Performance
Data Cooling English Units
TWJ020CA WITH TWE030CA4 AT 700 CFM (CAPACITIES ARE GROSS IN BTUH/1000-INDOOR FAN HEAT IGNORED)
O.D. I.D. TOTAL SENS. CAP. AT ENTERING D.B. TEMP. COMPR.
D.B.W.B.CAP. 7274767880 KW
59 18.2 15.5 16.7 18.0 18.6* 19.1* 1.34
85 63 19.7 13.0 14.3 15.5 16.8 18.1 1.39
67 21.2 10.3 11.6 12.8 14.1 15.4 1.44
71 22.7 7.5 8.8 10.1 11.3 12.6 1.49
59 17.9 15.3 16.6 17.8 18.4* 18.8* 1.40
90 63 19.3 12.8 14.1 15.4 16.7 17.9 1.45
67 20.8 10.1 11.4 12.7 13.9 15.2 1.50
71 22.3 7.4 8.6 9.9 11.2 12.4 1.55
59 17.5 15.2 16.4 17.6* 18.1* 18.5* 1.46
95 63 18.9 12.7 14.0 15.2 16.5 17.8 1.51
67 20.4 10.0 11.3 12.5 13.8 15.1 1.56
71 21.9 7.2 8.5 9.8 11.0 12.3 1.62
59 17.0 15.0 16.2 17.2* 17.7* 18.1* 1.53
100 63 18.4 12.5 13.8 15.0 16.3 17.6 1.58
67 19.8 9.8 11.0 12.3 13.6 14.9 1.63
71 21.3 7.0 8.3 9.5 10.8 12.1 1.68
59 16.5 14.7 16.0 16.8* 17.3* 17.7* 1.59
105 63 17.9 12.3 13.6 14.8 16.1 17.4 1.64
67 19.2 9.6 10.8 12.1 13.4 14.6 1.70
71 20.7 6.8 8.1 9.3 10.6 11.9 1.75
59 15.6 14.3 15.6* 16.0* 16.4* 16.9* 1.72
115 63 16.8 11.9 13.1 14.4 15.7 16.9* 1.78
67 18.1 9.2 10.4 11.7 13.0 14.2 1.83
71 19.4 6.4 7.7 8.9 10.2 11.5 1.89
CORRECTION FACTORS - OTHER AIRFLOWS
(MULTIPLY OR ADD AS INDICATED)
AIRFLOW 625 800
TOTAL CAP. X0.99 X1.01
SENS. CAP. X0.95 X1.06
COMPR. KW X0.99 X1.01
VALUES AT 95/80/67 RATING CONDITIONS
GROSS CAPACITY = 20400 BTUH
AIRFLOW = 700 CFM
COMPRESSOR POWER = 1562 WATTS
I.D. FAN POWER = 310 WATTS
O.D. FAN POWER = 130 WATTS
S.E.E.R. = 10.30 BTUH/WATT
E.E.R. = 9.50 BTUH/WATT
NOTE:RATED WITH 25 FEET OF 3/4 SUCT.
AND 5/16 LIQUID LINE
* DRY COIL CONDITION (TOTAL CAPACITY =
SENSIBLE CAPACITY)
TOTAL CAPACITY, COMP. KW AND APP. DEW PT.
ARE VALID ONLY FOR WET COIL
ALL TEMPERATURES IN DEGREES F.
TWJ024CA WITH TWE030CA4 AT 900 CFM (CAPACITIES ARE GROSS IN BTUH/1000-INDOOR FAN HEAT IGNORED)
O.D. I.D. TOTAL SENS. CAP. AT ENTERING D.B. TEMP. COMPR.
D.B.W.B.CAP. 7274767880 KW
59 24.2 19.7 21.3 22.9 24.3* 24.9* 1.92
85 63 26.0 16.7 18.3 19.8 21.4 23.0 1.98
67 28.0 13.3 14.9 16.5 18.0 19.6 2.05
71 30.0 9.9 11.5 13.0 14.6 16.2 2.12
59 23.8 19.6 21.1 22.7 24.0* 24.6* 2.01
90 63 25.6 16.5 18.1 19.7 21.2 22.8 2.08
67 27.5 13.2 14.7 16.3 17.9 19.4 2.14
71 29.5 9.7 11.3 12.8 14.4 16.0 2.21
59 23.4 19.4 21.0 22.5 23.7* 24.3* 2.10
95 63 25.2 16.4 17.9 19.5 21.0 22.6 2.17
67 27.1 13.0 14.5 16.1 17.7 19.2 2.24
71 29.0 9.5 11.1 12.7 14.2 15.8 2.31
59 22.8 19.2 20.7 22.3 23.2* 23.8* 2.21
100 63 24.6 16.1 17.7 19.2 20.8 22.4 2.27
67 26.4 12.7 14.3 15.9 17.4 19.0 2.34
71 28.3 9.3 10.9 12.4 14.0 15.6 2.41
59 22.2 18.9 20.5 22.0 22.8* 23.3* 2.31
105 63 24.0 15.9 17.4 19.0 20.6 22.1 2.37
67 25.7 12.5 14.1 15.6 17.2 18.8 2.44
71 27.6 9.0 10.6 12.2 13.7 15.3 2.51
59 21.1 18.4 20.0 21.3* 21.8* 22.4* 2.52
115 63 22.7 15.4 16.9 18.5 20.1 21.6 2.58
67 24.4 12.0 13.6 15.1 16.7 18.3 2.65
71 26.2 8.6 10.1 11.7 13.3 14.8 2.71
CORRECTION FACTORS - OTHER AIRFLOWS
(MULTIPLY OR ADD AS INDICATED)
AIRFLOW 800 1025
TOTAL CAP. X0.99 X1.01
SENS. CAP. X0.95 X1.06
COMPR. KW X0.99 X1.01
VALUES AT 95/80/67 RATING CONDITIONS
GROSS CAPACITY = 27100 BTUH
AIRFLOW = 900 CFM
COMPRESSOR POWER = 2239 WATTS
I.D. FAN POWER = 430 WATTS
O.D. FAN POWER = 180 WATTS
E.E.R. = 8.90 BTUH/WATT
NOTE:RATED WITH 25 FEET OF 3/4 SUCT.
AND 5/16 LIQUID LINE
* DRY COIL CONDITION (TOTAL CAPACITY =
SENSIBLE CAPACITY)
TOTAL CAPACITY, COMP. KW AND APP. DEW PT.
ARE VALID ONLY FOR WET COIL
ALL TEMPERATURES IN DEGREES F.
TWJ030CA WITH TWE030CA4 AT 1000 CFM (CAPACITIES ARE GROSS IN BTUH/1000-INDOOR FAN HEAT IGNORED)
O.D. I.D. TOTAL SENS. CAP. AT ENTERING D.B. TEMP. COMPR.
D.B.W.B.CAP. 7274767880 KW
59 29.0 22.8 24.5 26.2 28.0 29.3* 2.57
85 63 31.2 19.4 21.2 22.9 24.6 26.3 2.66
67 33.5 15.7 17.4 19.2 20.9 22.6 2.75
71 35.8 11.9 13.6 15.3 17.1 18.8 2.85
59 28.5 22.6 24.3 26.0 27.7 28.9* 2.69
90 63 30.6 19.2 20.9 22.7 24.4 26.1 2.78
67 32.9 15.5 17.2 18.9 20.7 22.4 2.88
71 35.2 11.7 13.4 15.1 16.9 18.6 2.97
59 28.0 22.3 24.1 25.8 27.5 28.5* 2.82
95 63 30.1 19.0 20.7 22.4 24.2 25.9 2.91
67 32.3 15.3 17.0 18.7 20.4 22.2 3.00
71 34.6 11.5 13.2 14.9 16.6 18.4 3.10
59 27.3 22.1 23.8 25.5 27.2 28.0* 2.95
100 63 29.4 18.7 20.4 22.1 23.9 25.6 3.04
67 31.5 15.0 16.7 18.4 20.1 21.9 3.13
71 33.8 11.2 12.9 14.6 16.3 18.1 3.23
59 26.6 21.8 23.5 25.2 26.8* 27.4* 3.08
105 63 28.7 18.4 20.1 21.9 23.6 25.3 3.17
67 30.8 14.7 16.4 18.1 19.9 21.6 3.26
71 32.9 10.9 12.6 14.3 16.1 17.8 3.36
59 25.3 21.2 22.9 24.6 25.7* 26.3* 3.35
115 63 27.2 17.8 19.6 21.3 23.0 24.7 3.43
67 29.2 14.1 15.8 17.6 19.3 21.0 3.52
71 31.3 10.3 12.0 13.8 15.5 17.2 3.62
CORRECTION FACTORS - OTHER AIRFLOWS
(MULTIPLY OR ADD AS INDICATED)
AIRFLOW 875 1125
TOTAL CAP. X0.98 X1.01
SENS. CAP. X0.95 X1.05
COMPR. KW X0.99 X1.01
VALUES AT 95/80/67 RATING CONDITIONS
GROSS CAPACITY = 32400 BTUH
AIRFLOW = 1000 CFM
COMPRESSOR POWER = 3002 WATTS
I.D. FAN POWER = 440 WATTS
O.D. FAN POWER = 195 WATTS
E.E.R. = 8.30 BTUH/WATT
NOTE:RATED WITH 25 FEET OF 7/8 SUCT.
AND 3/8 LIQUID LINE
* DRY COIL CONDITION (TOTAL CAPACITY =
SENSIBLE CAPACITY)
TOTAL CAPACITY, COMP. KW AND APP. DEW PT.
ARE VALID ONLY FOR WET COIL
ALL TEMPERATURES IN DEGREES F.
