16 TWE5-PRC001-EN-10-15-99
Performance
Data Heating English Units
TWJ020CA WITH TWE030CA4 AT 700 CFM
O.D. HEATING CAPACITY (BTUH/1000) AT TOTAL POWER IN KILOWATTS AT
TEMP. INDICATED INDOOR DRY BULB TEMP. INDICATED INDOOR DRY BULB TEMP.
F. 60 70 75 80 60 70 75 80
-18 0.00 0.00 0.00 0.00 0.00 0.00 0.00 0.00
-13 0.00 0.00 0.00 0.00 0.00 0.00 0.00 0.00
-8 0.00 0.00 0.00 0.00 0.00 0.00 0.00 0.00
-3 0.00 0.00 0.00 0.00 0.00 0.00 0.00 0.00
2 6.79 6.60 6.50 6.41 1.47 1.54 1.58 1.61
7 8.13 7.90 7.78 7.67 1.50 1.57 1.61 1.64
12 9.48 9.20 9.06 8.92 1.52 1.60 1.63 1.67
17 10.8 10.5 10.3 10.2 1.55 1.63 1.66 1.70
22 11.2 10.9 10.7 10.5 1.56 1.64 1.68 1.71
27 11.6 11.2 11.0 10.9 1.57 1.65 1.69 1.73
32 11.9 11.6 11.4 11.2 1.58 1.66 1.70 1.74
37 12.3 11.9 11.8 11.6 1.60 1.68 1.71 1.75
42 12.7 12.3 12.1 11.9 1.61 1.69 1.73 1.77
47 18.9 18.3 18.0 17.7 1.71 1.79 1.84 1.88
52 20.2 19.6 19.3 19.0 1.73 1.82 1.87 1.91
57 21.6 20.9 20.6 20.2 1.76 1.85 1.90 1.94
62 22.9 22.2 21.8 21.5 1.79 1.88 1.92 1.97
67 24.3 23.5 23.1 22.7 1.81 1.91 1.95 2.00
72 25.6 24.8 24.4 24.0 1.84 1.93 1.98 2.03
CORRECTION FACTORS - OTHER AIRFLOWS
(VALUE AT 700 CFM TIMES CORR. FACTOR
= VALUE AT NEW AIRFLOW)
AIRFLOW 625 800
HEATING CAP. X0.99 X1.02
COMPR. KW X1.01 X0.98
VALUES AT ARI RATING CONDITIONS OF:
70&47/43 (HIGH TEMP. POINT)
70&17/15 (LOW TEMP. POINT)
AIRFLOW = 700 CFM
HEATING CAP. (HIGH TEMP.) = 18300 BTUH
HEATING CAP. (LOW TEMP.) = 10500 BTUH
COMPR. POWER (HIGH TEMP.) = 1354 WATTS
COMPR. POWER (LOW TEMP.) = 1185 WATTS
COEFF. OF PERF. (HIGH TEMP.) = 3.00
COEFF. OF PERF. (LOW TEMP.) = 1.88
OUTDOOR FAN POWER = 130 WATTS
INDOOR FAN POWER = 310 WATTS
NOTE: RATED WITH 25 FEET OF 3/4
SUCTION AND 5/16 LIQUID LINE
TWJ024CA WITH TWE030CA4 AT 900 CFM
O.D. HEATING CAPACITY (BTUH/1000) AT TOTAL POWER IN KILOWATTS AT
TEMP. INDICATED INDOOR DRY BULB TEMP. INDICATED INDOOR DRY BULB TEMP.
F. 60 70 75 80 60 70 75 80
-18 0.00 0.00 0.00 0.00 0.00 0.00 0.00 0.00
-13 0.00 0.00 0.00 0.00 0.00 0.00 0.00 0.00
-8 0.00 0.00 0.00 0.00 0.00 0.00 0.00 0.00
-3 8.10 7.93 7.85 7.77 1.86 1.94 1.98 2.03
2 9.91 9.70 9.60 9.49 1.92 2.01 2.06 2.10
7 11.7 11.5 11.3 11.2 1.99 2.08 2.13 2.17
12 13.5 13.2 13.1 12.9 2.06 2.15 2.20 2.25
17 15.3 15.0 14.8 14.7 2.12 2.22 2.27 2.32
22 16.2 15.9 15.7 15.5 2.18 2.28 2.33 2.38
27 17.1 16.7 16.5 16.3 2.23 2.34 2.39 2.44
32 18.0 17.6 17.4 17.2 2.29 2.40 2.45 2.51
37 18.9 18.4 18.2 18.0 2.34 2.45 2.51 2.57
42 19.8 19.3 19.1 18.9 2.39 2.51 2.57 2.63
47 26.2 25.6 25.3 25.0 2.52 2.65 2.71 2.77
52 28.0 27.4 27.0 26.7 2.59 2.72 2.78 2.85
57 29.8 29.1 28.8 28.4 2.66 2.79 2.86 2.92
62 31.6 30.9 30.5 30.2 2.72 2.86 2.93 3.00
67 33.5 32.7 32.3 31.9 2.79 2.93 3.00 3.07
72 35.3 34.4 34.0 33.6 2.86 3.00 3.07 3.14
CORRECTION FACTORS - OTHER AIRFLOWS
(VALUE AT 900 CFM TIMES CORR. FACTOR
= VALUE AT NEW AIRFLOW)
AIRFLOW 800 1025
HEATING CAP. X0.99 X1.02
COMPR. KW X1.02 X0.98
VALUES AT ARI RATING CONDITIONS OF:
70&47/43 (HIGH TEMP. POINT)
70&17/15 (LOW TEMP. POINT)
AIRFLOW = 900 CFM
HEATING CAP. (HIGH TEMP.) = 25600 BTUH
HEATING CAP. (LOW TEMP.) = 15000 BTUH
COMPR. POWER (HIGH TEMP.) = 2038 WATTS
COMPR. POWER (LOW TEMP.) = 1614 WATTS
COEFF. OF PERF. (HIGH TEMP.) = 2.84
COEFF. OF PERF. (LOW TEMP.) = 1.96
OUTDOOR FAN POWER = 180 WATTS
INDOOR FAN POWER = 430 WATTS
NOTE: RATED WITH 25 FEET OF 3/4
SUCTION AND 5/16 LIQUID LINE
TWJ030CA WITH TWE030CA4 AT 1000 CFM
O.D. HEATING CAPACITY (BTUH/1000) AT TOTAL POWER IN KILOWATTS AT
TEMP. INDICATED INDOOR DRY BULB TEMP. INDICATED INDOOR DRY BULB TEMP.
F. 60 70 75 80 60 70 75 80
-18 0.00 0.00 0.00 0.00 0.00 0.00 0.00 0.00
-13 0.00 0.00 0.00 0.00 0.00 0.00 0.00 0.00
-8 0.00 0.00 0.00 0.00 0.00 0.00 0.00 0.00
-3 9.79 9.60 9.51 9.41 2.27 2.38 2.44 2.49
2 11.8 11.6 11.5 11.4 2.36 2.47 2.53 2.59
7 13.9 13.6 13.5 13.3 2.44 2.56 2.62 2.69
12 15.9 15.6 15.4 15.3 2.53 2.65 2.72 2.78
17 18.0 17.6 17.4 17.2 2.61 2.74 2.81 2.88
22 18.9 18.5 18.3 18.2 2.69 2.83 2.89 2.96
27 19.9 19.5 19.3 19.1 2.77 2.91 2.98 3.05
32 20.9 20.4 20.2 20.0 2.85 2.99 3.06 3.14
37 21.8 21.4 21.2 20.9 2.92 3.07 3.15 3.22
42 22.8 22.3 22.1 21.8 3.00 3.16 3.23 3.31
47 30.2 29.6 29.3 29.0 3.12 3.28 3.37 3.45
52 32.3 31.6 31.3 30.9 3.21 3.37 3.46 3.54
57 34.3 33.6 33.2 32.9 3.29 3.46 3.55 3.64
62 36.4 35.6 35.2 34.8 3.38 3.55 3.64 3.73
67 38.4 37.6 37.2 36.8 3.46 3.64 3.74 3.83
72 40.5 39.6 39.2 38.7 3.55 3.73 3.83 3.92
CORRECTION FACTORS - OTHER AIRFLOWS
(VALUE AT 1000 CFM TIMES CORR. FACTOR
= VALUE AT NEW AIRFLOW)
AIRFLOW 875 1125
HEATING CAP. X0.99 X1.01
COMPR. KW X1.02 X0.98
VALUES AT ARI RATING CONDITIONS OF:
70&47/43 (HIGH TEMP. POINT)
70&17/15 (LOW TEMP. POINT)
AIRFLOW = 1000 CFM
HEATING CAP. (HIGH TEMP.) = 29600 BTUH
HEATING CAP. (LOW TEMP.) = 17600 BTUH
COMPR. POWER (HIGH TEMP.) = 2649 WATTS
COMPR. POWER (LOW TEMP.) = 2109 WATTS
COEFF. OF PERF. (HIGH TEMP.) = 2.64
COEFF. OF PERF. (LOW TEMP.) = 1.86
OUTDOOR FAN POWER = 195 WATTS
INDOOR FAN POWER = 440 WATTS
NOTE: RATED WITH 25 FEET OF 7/8
SUCTION AND 3/8 LIQUID LINE
