Trane TWE030CA User Manual

TWE5-PRC001-EN-10-15-99 17
Performance
Data Heating Metric Units
TWJ020CA WITH TWE030CA4 AT 1189 CMH
O.D. HEATING CAPACITY IN KILOWATTS AT TOTAL POWER IN KILOWATTS AT
TEMP. INDICATED INDOOR DRY BULB TEMP. INDICATED INDOOR DRY BULB TEMP.
C. 15.6 21.1 23.9 26.7 15.6 21.1 23.9 26.7
-27.8 0.0 0.0 0.0 0.0 0.0 0.0 0.0 0.0
-25.0 0.0 0.0 0.0 0.0 0.0 0.0 0.0 0.0
-22.2 0.0 0.0 0.0 0.0 0.0 0.0 0.0 0.0
-19.4 0.0 0.0 0.0 0.0 0.0 0.0 0.0 0.0
-16.7 2.0 1.9 1.9 1.9 1.5 1.5 1.6 1.6
-13.9 2.4 2.3 2.3 2.2 1.5 1.6 1.6 1.6
-11.1 2.8 2.7 2.7 2.6 1.5 1.6 1.6 1.7
-8.3 3.2 3.1 3.0 3.0 1.5 1.6 1.7 1.7
-5.6 3.3 3.2 3.1 3.1 1.6 1.6 1.7 1.7
-2.8 3.4 3.3 3.2 3.2 1.6 1.6 1.7 1.7
0.0 3.5 3.4 3.3 3.3 1.6 1.7 1.7 1.7
2.8 3.6 3.5 3.5 3.4 1.6 1.7 1.7 1.8
5.6 3.7 3.6 3.5 3.5 1.6 1.7 1.7 1.8
8.3 5.5 5.4 5.3 5.2 1.7 1.8 1.8 1.9
11.1 5.9 5.7 5.7 5.6 1.7 1.8 1.9 1.9
13.9 6.3 6.1 6.0 5.9 1.8 1.9 1.9 1.9
16.7 6.7 6.5 6.4 6.3 1.8 1.9 1.9 2.0
19.4 7.1 6.9 6.8 6.7 1.8 1.9 2.0 2.0
22.2 7.5 7.3 7.1 7.0 1.8 1.9 2.0 2.0
CORRECTION FACTORS - OTHER AIRFLOWS
(VALUE AT 1189 CMH TIMES CORR. FACTOR
= VALUE AT NEW AIRFLOW)
AIRFLOW 1061 1358
HEATING CAP. X0.99 X1.02
COMPR. KW X1.01 X0.98
VALUES AT ARI RATING CONDITIONS OF:
21.1& 8.3/6.1(HIGH TEMP. POINT)
21.1&-8.3/-9.4(LOW TEMP. POINT)
AIRFLOW = 1189 CMH
HEATING CAP. (HIGH TEMP.) = 5.36 KW
HEATING CAP. (LOW TEMP.) = 3.08 KW
COMPR. POWER (HIGH TEMP.) = 1354 WATTS
COMPR. POWER (LOW TEMP.) = 1185 WATTS
COEFF. OF PERF. (HIGH TEMP.) = 3.00
COEFF. OF PERF. (LOW TEMP.) = 1.88
OUTDOOR FAN POWER = 130 WATTS
INDOOR FAN POWER = 310 WATTS
NOTE: RATED WITH 7.62 METERS OF 19 MM
SUCTION AND 8 MM LIQUID LINE
TWJ024CA WITH TWE030CA4 AT 1528 CMH
O.D. HEATING CAPACITY IN KILOWATTS AT TOTAL POWER IN KILOWATTS AT
TEMP. INDICATED INDOOR DRY BULB TEMP. INDICATED INDOOR DRY BULB TEMP.
C. 15.6 21.1 23.9 26.7 15.6 21.1 23.9 26.7
-27.8 0.0 0.0 0.0 0.0 0.0 0.0 0.0 0.0
-25.0 0.0 0.0 0.0 0.0 0.0 0.0 0.0 0.0
-22.2 0.0 0.0 0.0 0.0 0.0 0.0 0.0 0.0
-19.4 2.4 2.3 2.3 2.3 1.9 1.9 2.0 2.0
-16.7 2.9 2.8 2.8 2.8 1.9 2.0 2.1 2.1
-13.9 3.4 3.4 3.3 3.3 2.0 2.1 2.1 2.2
-11.1 4.0 3.9 3.8 3.8 2.1 2.2 2.2 2.3
-8.3 4.5 4.4 4.3 4.3 2.1 2.2 2.3 2.3
-5.6 4.7 4.7 4.6 4.5 2.2 2.3 2.3 2.4
-2.8 5.0 4.9 4.8 4.8 2.2 2.3 2.4 2.4
0.0 5.3 5.2 5.1 5.0 2.3 2.4 2.5 2.5
2.8 5.5 5.4 5.3 5.3 2.3 2.5 2.5 2.6
5.6 5.8 5.7 5.6 5.5 2.4 2.5 2.6 2.6
8.3 7.7 7.5 7.4 7.3 2.5 2.7 2.7 2.8
11.1 8.2 8.0 7.9 7.8 2.6 2.7 2.8 2.8
13.9 8.7 8.5 8.4 8.3 2.7 2.8 2.9 2.9
16.7 9.3 9.1 8.9 8.8 2.7 2.9 2.9 3.0
19.4 9.8 9.6 9.5 9.3 2.8 2.9 3.0 3.1
22.2 10.3 10.1 10.0 9.8 2.9 3.0 3.1 3.1
CORRECTION FACTORS - OTHER AIRFLOWS
(VALUE AT 1528 CMH TIMES CORR. FACTOR
= VALUE AT NEW AIRFLOW)
AIRFLOW 1358 1741
HEATING CAP. X0.99 X1.02
COMPR. KW X1.02 X0.98
VALUES AT ARI RATING CONDITIONS OF:
21.1& 8.3/6.1(HIGH TEMP. POINT)
21.1&-8.3/-9.4(LOW TEMP. POINT)
AIRFLOW = 1528 CMH
HEATING CAP. (HIGH TEMP.) = 7.50 KW
HEATING CAP. (LOW TEMP.) = 4.39 KW
COMPR. POWER (HIGH TEMP.) = 2038 WATTS
COMPR. POWER (LOW TEMP.) = 1614 WATTS
COEFF. OF PERF. (HIGH TEMP.) = 2.84
COEFF. OF PERF. (LOW TEMP.) = 1.96
OUTDOOR FAN POWER = 180 WATTS
INDOOR FAN POWER = 430 WATTS
NOTE: RATED WITH 7.62 METERS OF 19 MM
SUCTION AND 8 MM LIQUID LINE
TWJ030CA WITH TWE030CA4 AT 1698 CMH
O.D. HEATING CAPACITY IN KILOWATTS AT TOTAL POWER IN KILOWATTS AT
TEMP. INDICATED INDOOR DRY BULB TEMP. INDICATED INDOOR DRY BULB TEMP.
C. 15.6 21.1 23.9 26.7 15.6 21.1 23.9 26.7
-27.8 0.0 0.0 0.0 0.0 0.0 0.0 0.0 0.0
-25.0 0.0 0.0 0.0 0.0 0.0 0.0 0.0 0.0
-22.2 0.0 0.0 0.0 0.0 0.0 0.0 0.0 0.0
-19.4 2.9 2.8 2.8 2.8 2.3 2.4 2.4 2.5
-16.7 3.5 3.4 3.4 3.3 2.4 2.5 2.5 2.6
-13.9 4.1 4.0 4.0 3.9 2.4 2.6 2.6 2.7
-11.1 4.7 4.6 4.5 4.5 2.5 2.7 2.7 2.8
-8.3 5.3 5.2 5.1 5.0 2.6 2.7 2.8 2.9
-5.6 5.5 5.4 5.4 5.3 2.7 2.8 2.9 3.0
-2.8 5.8 5.7 5.7 5.6 2.8 2.9 3.0 3.0
0.0 6.1 6.0 5.9 5.9 2.8 3.0 3.1 3.1
2.8 6.4 6.3 6.2 6.1 2.9 3.1 3.2 3.2
5.6 6.7 6.5 6.5 6.4 3.0 3.2 3.2 3.3
8.3 8.8 8.7 8.6 8.5 3.1 3.3 3.4 3.5
11.1 9.5 9.3 9.2 9.1 3.2 3.4 3.5 3.5
13.9 10.0 9.8 9.7 9.6 3.3 3.5 3.5 3.6
16.7 10.7 10.4 10.3 10.2 3.4 3.5 3.6 3.7
19.4 11.3 11.0 10.9 10.8 3.5 3.6 3.7 3.8
22.2 11.9 11.6 11.5 11.3 3.5 3.7 3.8 3.9
CORRECTION FACTORS - OTHER AIRFLOWS
(VALUE AT 1698 CMH TIMES CORR. FACTOR
= VALUE AT NEW AIRFLOW)
AIRFLOW 1486 1910
HEATING CAP. X0.99 X1.01
COMPR. KW X1.02 X0.98
VALUES AT ARI RATING CONDITIONS OF:
21.1& 8.3/6.1(HIGH TEMP. POINT)
21.1&-8.3/-9.4(LOW TEMP. POINT)
AIRFLOW = 1698 CMH
HEATING CAP. (HIGH TEMP.) = 8.67 KW
HEATING CAP. (LOW TEMP.) = 5.16 KW
COMPR. POWER (HIGH TEMP.) = 2649 WATTS
COMPR. POWER (LOW TEMP.) = 2109 WATTS
COEFF. OF PERF. (HIGH TEMP.) = 2.64
COEFF. OF PERF. (LOW TEMP.) = 1.86
OUTDOOR FAN POWER = 195 WATTS
INDOOR FAN POWER = 440 WATTS
NOTE: RATED WITH 7.62 METERS OF 22 MM
SUCTION AND 9.5 MM LIQUID LINE
