18 TWE5-PRC001-EN-10-15-99
Performance
Data Heating English Units
TWJ030CA WITH TWE040CA4-B AT 1100 CFM
O.D. HEATING CAPACITY (BTUH/1000) AT TOTAL POWER IN KILOWATTS AT
TEMP. INDICATED INDOOR DRY BULB TEMP. INDICATED INDOOR DRY BULB TEMP.
F. 60 70 75 80 60 70 75 80
-18 0.00 0.00 0.00 0.00 0.00 0.00 0.00 0.00
-13 0.00 0.00 0.00 0.00 0.00 0.00 0.00 0.00
-8 0.00 0.00 0.00 0.00 0.00 0.00 0.00 0.00
-3 9.46 9.27 9.17 9.08 2.12 2.24 2.30 2.36
2 11.6 11.3 11.2 11.1 2.19 2.31 2.37 2.44
7 13.6 13.4 13.2 13.1 2.26 2.39 2.45 2.52
12 15.7 15.4 15.2 15.1 2.33 2.47 2.53 2.60
17 17.8 17.5 17.3 17.1 2.40 2.54 2.61 2.68
22 18.9 18.5 18.3 18.1 2.47 2.61 2.68 2.76
27 19.9 19.5 19.3 19.1 2.54 2.69 2.76 2.83
32 21.0 20.5 20.3 20.1 2.61 2.76 2.83 2.91
37 22.0 21.6 21.3 21.1 2.67 2.83 2.91 2.99
42 23.1 22.6 22.3 22.1 2.74 2.90 2.98 3.06
47 30.4 29.7 29.4 29.1 2.83 3.00 3.08 3.17
52 32.5 31.8 31.4 31.1 2.91 3.08 3.16 3.25
57 34.6 33.8 33.5 33.1 2.98 3.15 3.24 3.33
62 36.7 35.9 35.5 35.1 3.05 3.23 3.32 3.41
67 38.8 37.9 37.5 37.1 3.12 3.31 3.40 3.49
72 40.9 40.0 39.5 39.1 3.19 3.38 3.48 3.57
CORRECTION FACTORS - OTHER AIRFLOWS
(VALUE AT 1100 CFM TIMES CORR. FACTOR
= VALUE AT NEW AIRFLOW)
AIRFLOW 975 1275
HEATING CAP. X0.99 X1.01
COMPR. KW X1.02 X0.98
VALUES AT ARI RATING CONDITIONS OF:
70&47/43 (HIGH TEMP. POINT)
70&17/15 (LOW TEMP. POINT)
AIRFLOW = 1125 CFM
HEATING CAP. (HIGH TEMP.) = 29800 BTUH
HEATING CAP. (LOW TEMP.) = 17500 BTUH
COMPR. POWER (HIGH TEMP.) = 2504 WATTS
COMPR. POWER (LOW TEMP.) = 2047 WATTS
COEFF. OF PERF. (HIGH TEMP.) = 2.92
COEFF. OF PERF. (LOW TEMP.) = 2.00
OUTDOOR FAN POWER = 195 WATTS
INDOOR FAN POWER = 300 WATTS
NOTE: RATED WITH 25 FEET OF 7/8
SUCTION AND 3/8 LIQUID LINE
TWJ036CA WITH TWE030CA4 AT 1100 CFM
O.D. HEATING CAPACITY (BTUH/1000) AT TOTAL POWER IN KILOWATTS AT
TEMP. INDICATED INDOOR DRY BULB TEMP. INDICATED INDOOR DRY BULB TEMP.
F. 60 70 75 80 60 70 75 80
-18 0.00 0.00 0.00 0.00 0.00 0.00 0.00 0.00
-13 0.00 0.00 0.00 0.00 0.00 0.00 0.00 0.00
-8 8.32 8.18 8.11 8.04 2.00 2.09 2.13 2.18
-3 10.8 10.6 10.5 10.4 2.13 2.22 2.27 2.32
2 13.3 13.0 12.9 12.8 2.25 2.36 2.41 2.46
7 15.8 15.5 15.3 15.2 2.38 2.49 2.54 2.60
12 18.3 17.9 17.7 17.5 2.50 2.62 2.68 2.74
17 20.7 20.3 20.1 19.9 2.63 2.75 2.82 2.88
22 21.9 21.5 21.3 21.1 2.71 2.85 2.91 2.98
27 23.1 22.7 22.4 22.2 2.80 2.94 3.01 3.08
32 24.3 23.8 23.6 23.3 2.89 3.03 3.10 3.18
37 25.5 25.0 24.7 24.5 2.98 3.13 3.20 3.27
42 26.7 26.2 25.9 25.6 3.06 3.22 3.30 3.37
47 35.6 34.9 34.5 34.2 3.38 3.55 3.64 3.72
52 38.1 37.3 36.9 36.6 3.50 3.68 3.77 3.87
57 40.6 39.8 39.3 38.9 3.63 3.82 3.91 4.01
62 43.1 42.2 41.8 41.3 3.75 3.95 4.05 4.15
67 45.6 44.6 44.2 43.7 3.88 4.08 4.19 4.29
72 48.0 47.1 46.6 46.1 4.00 4.22 4.32 4.43
CORRECTION FACTORS - OTHER AIRFLOWS
(VALUE AT 1100 CFM TIMES CORR. FACTOR
= VALUE AT NEW AIRFLOW)
AIRFLOW 975 1275
HEATING CAP. X0.99 X1.02
COMPR. KW X1.02 X0.97
VALUES AT ARI RATING CONDITIONS OF:
70&47/43 (HIGH TEMP. POINT)
70&17/15 (LOW TEMP. POINT)
AIRFLOW = 1125 CFM
HEATING CAP. (HIGH TEMP.) = 35000 BTUH
HEATING CAP. (LOW TEMP.) = 20400 BTUH
COMPR. POWER (HIGH TEMP.) = 2776 WATTS
COMPR. POWER (LOW TEMP.) = 1982 WATTS
COEFF. OF PERF. (HIGH TEMP.) = 2.88
COEFF. OF PERF. (LOW TEMP.) = 2.16
OUTDOOR FAN POWER = 235 WATTS
INDOOR FAN POWER = 540 WATTS
NOTE: RATED WITH 25 FEET OF 7/8
SUCTION AND 3/8 LIQUID LINE
TWJ036CA WITH TWE040CA4-B AT 1400 CFM
O.D. HEATING CAPACITY (BTUH/1000) AT TOTAL POWER IN KILOWATTS AT
TEMP. INDICATED INDOOR DRY BULB TEMP. INDICATED INDOOR DRY BULB TEMP.
F. 60 70 75 80 60 70 75 80
-18 0.00 0.00 0.00 0.00 0.00 0.00 0.00 0.00
-13 0.00 0.00 0.00 0.00 0.00 0.00 0.00 0.00
-8 7.73 7.59 7.52 7.45 1.84 1.93 1.98 2.03
-3 10.3 10.1 10.0 9.94 1.94 2.05 2.10 2.15
2 12.9 12.7 12.5 12.4 2.05 2.16 2.22 2.27
7 15.5 15.2 15.1 14.9 2.16 2.27 2.33 2.39
12 18.1 17.7 17.6 17.4 2.26 2.39 2.45 2.52
17 20.7 20.3 20.1 19.9 2.37 2.50 2.57 2.64
22 22.0 21.6 21.3 21.1 2.44 2.58 2.65 2.72
27 23.3 22.8 22.6 22.4 2.52 2.66 2.73 2.81
32 24.6 24.1 23.9 23.6 2.59 2.74 2.82 2.89
37 25.9 25.4 25.1 24.9 2.67 2.82 2.90 2.97
42 27.2 26.7 26.4 26.1 2.74 2.90 2.98 3.06
47 36.3 35.5 35.1 34.8 3.00 3.18 3.27 3.36
52 38.9 38.1 37.7 37.2 3.11 3.29 3.39 3.48
57 41.5 40.6 40.2 39.7 3.22 3.41 3.50 3.60
62 44.1 43.1 42.7 42.2 3.32 3.52 3.62 3.72
67 46.6 45.7 45.2 44.7 3.43 3.63 3.74 3.84
72 49.2 48.2 47.7 47.2 3.54 3.75 3.85 3.96
CORRECTION FACTORS - OTHER AIRFLOWS
(VALUE AT 1400 CFM TIMES CORR. FACTOR
= VALUE AT NEW AIRFLOW)
AIRFLOW 1175 1525
HEATING CAP. X0.98 X1.01
COMPR. KW X1.03 X0.99
VALUES AT ARI RATING CONDITIONS OF:
70&47/43 (HIGH TEMP. POINT)
70&17/15 (LOW TEMP. POINT)
AIRFLOW = 1350 CFM
HEATING CAP. (HIGH TEMP.) = 35400 BTUH
HEATING CAP. (LOW TEMP.) = 20200 BTUH
COMPR. POWER (HIGH TEMP.) = 2590 WATTS
COMPR. POWER (LOW TEMP.) = 1906 WATTS
COEFF. OF PERF. (HIGH TEMP.) = 3.24
COEFF. OF PERF. (LOW TEMP.) = 2.36
OUTDOOR FAN POWER = 235 WATTS
INDOOR FAN POWER = 360 WATTS
NOTE: RATED WITH 25 FEET OF 7/8
SUCTION AND 3/8 LIQUID LINE
