24 WSHP-SVX04A-EN
Table E3: WPHF Electrical Performance (Standard Static Blower Option-continued)
Table E4: WPHF Electrical Performance (High Static Blower Option)
Model No. Volts/Hz/Ph
Blower Motor
HP
Blower Motor
FLA
Compr.
RLA
Compr.
MCC
Compr.
LRA
Minimum Cir-
cuit Amps
UL Max Fuse
or HACR
CSA
Max. Fuse
Size
CASE
Max.
Circuit Brkr
WPHF057 208/60/1 1/2 4.1 22.3 34.8 122 32.0 50 60 50
WPHF057 230/60/1 1/2 4.1 22.3 34.8 122 32.0 50 60 50
WPHF057 208/60/3 1/2 4.1 14.4 25.5 101 22.1 35 50 45
WPHF057 230/60/3 1/2 4.1 14.4 25.5 101 22.1 35 50 45
WPHF057 460/60/3 1/2 1.8 7.1 11.1 51 10.7 15 20 20
Model No. Volts/Hz/Ph
Blower Motor
HP
Blower Motor
FLA
Compr.
RLA
Compr.
MCC
Compr.
LRA
Minimum Cir-
cuit Amps
UL Max Fuse
or HACR
CSA
Max. Fuse
Size
CASE
Max.
Circuit Brkr
WPHF047 208/60/1 1/2 4.6 14.6 22.8 92 22.9 35 50 40
WPHF047 230/60/1 1/2 4.6 14.6 22.8 92 22.9 35 50 40
WPHF047 208/60/3 1/2 4.6 10.6 16.5 101 17.9 25 50 45
WPHF047 230/60/3 1/2 4.6 10.6 16.5 101 17.9 25 50 45
WPHF047 460/60/3 1/2 2.2 4.2 6.6 51 7.5 15 25 20
WPHF057 208/60/1 1/2 4.6 22.3 34.8 122 32.5 50 60 50
WPHF057 230/60/1 1/2 4.6 22.3 34.8 122 32.5 50 60 50
WPHF057 208/60/3 1/2 4.6 14.4 22.5 101 22.6 35 50 45
WPHF057 230/60/3 1/2 4.6 14.4 22.5 101 22.6 35 50 45
WPHF057 460/60/3 1/2 2.2 7.1 11.1 51 11.1 15 25 20
Electrical
Requirements
