Trane XR16 4TTR6 User Manual

22-1889-01 5
Product Specifications
Model No. 1 4TTR6042B1000A 4TTR6048B1000A 4TTR6049B1000A 4TTR6060B1000A 4TTR6061B000A
Electrical Data V/Ph/Hz 2 208/230/1/60 208/230/1/60 208/230/1/60 208/230/1/60 230/1/60
Min Cir Ampacity 23 26 26 34 45
Max Fuse Size (Amps) 40 45 45 60 60
Compressors CLIMATUFF
® -
SCROLL CLIMATUFF
® -
SCROLL CLIMATUFF
® -
SCROLL CLIMATUFF
® -
SCROLL CLIMATUFF
® -
SCROLL
No. Used - No. Stages 1-1 1-1 1-1 1-1 1-2
RL AMPS - LR AMPS 17.9 - 112 19.9 - 109 19.9 - 109 26.4 - 134 32.1 - 152.9
Outdoor Fan FL Amps 0.93 0.93 1.00 0.93 2.80
Fan HP 1/5 1/5 1/5 1/5 1/3
Fan Dia (inches) 27.6 27.6 27.6 27.6 27.6
Coil Spine Fin™ Spine Fin™ Spine Fin™ Spine Fin™ Spine Fin™
Refrigerant R-410A 8/4-LB/OZ 8/5-LB/OZ 11/9-LB/OZ 8/8-LB/OZ 12/9-LB/OZ
Line Size - (in.) O.D. Gas 3 7/8 7/8 7/8 7/8 1-1/8
Line Size - (in.) O.D. Liquid 3 3/8 3/8 3/8 3/8 3/8
Dimensions H x W x D (Crated) 46.4 x 35.1 x 38.7 51 x 35.1 x 38.7 51 x 35.1 x 38.7 51 x 35.1 x 38.7 51 x 35.1 x 38.7
Weight - Shipping 272 282 304 285 312
Weight - Net 235 245 267 248 275
Start Components NO NO NO NO NO
Sound Enclosure YES YES NO YES NO
Compressor Sump Heat NO NO NO NO NO
Optional Accessories: 4
Anti-short Cycle Timer TAYASCT501A TAYASCT501A TAYASCT501A TAYASCT501A TAYASCT501A
Evaporator Defrost Control A/C AY28X079 AY28X079 AY28X079 AY28X079 AY28X079
Rubber Isolator Kit BAYISLT101 BAYISLT101 BAYISLT101 BAYISLT101 BAYISLT101
Crank Case Heater Kit BAYCCHT301 BAYCCHT301 BAYCCHT301 BAYCCHT301 BAYCCHT301
Hard Start Kit Scroll BAYKSKT260 BAYKSKT260 BAYKSKT260 BAYKSKT263 BAYKSKT263
Extreme Condition Mounting Kit BAYECMT004 BAYECMT004 BAYECMT004 BAYECMT004 BAYECMT004
Snow Leg - Base & Cap 4" High BAYLEGS002 BAYLEGS002 BAYLEGS002 BAYLEGS002 BAYLEGS002
Snow Leg - 4" Extension BAYLEGS003 BAYLEGS003 BAYLEGS003 BAYLEGS003 BAYLEGS003
Seacoast Kit BAYSEAC001 BAYSEAC001 BAYSEAC001 BAYSEAC001 BAYSEAC001
Refrigerant Lineset 5 TAYREFLN3* TAYREFLN3* TAYREFLN3* TAYREFLN3* TAYREFLN*4
1 Certified in accordance with the Air-Source Unitary Heat Pump Equipment certification program which is based on AHRI Standard 210/240.
2 Calculated in accordance with N.E.C. Only use HACR circuit breakers or fuses.
3 Standard line lengths - 60'. Standard lift - 60' Suction and Liquid line. For 061 units, Max. linear length 60 ft.; Max. lift - Suction 25 ft.; Max lift - Liquid 25 ft.
For Greater lengths and lifts refer to refrigerant piping software Pub# 32-3312-0
†
. (
†
denotes latest revision)
4 For accessory description and usage, see page 5.
5 * = 15, 20, 25, 30, 40 and 50 foot lineset available.
