4 22-1889-01
Product Specifications
Model No. 1 4TTR6018B1000A 4TTR6024B1000A 4TTR6030B1000A 4TTR6036B1000A
Electrical Data V/Ph/Hz 2 208/230/1/60 208/230/1/60 208/230/1/60 208/230/1/60
Min Cir Ampacity 9 9 12 19
Max Fuse Size (Amps) 15 15 20 30
Compressors CLIMATUFF
®
CLIMATUFF
®
CLIMATUFF
®
CLIMATUFF
® -
SCROLL
No. Used - No. Stages 1-1 1-1 1-1 1-1
RL AMPS - LR AMPS 6.4 - 38.6 6.8 - 38.6 9.1 - 57.8 14.1 - 77
Outdoor Fan FL Amps 0.74 0.74 0.93 0.93
Fan HP 1/8 1/8 1/5 1/5
Fan Dia (inches) 23 23 27.6 27.6
Coil Spine Fin™ Spine Fin™ Spine Fin™ Spine Fin™
Refrigerant R-410A 5/2-LB/OZ 6/3-LB/OZ 7/0-LB/OZ 7/4-LB/OZ
Line Size - (in.) O.D. Gas 3 5/8 3/4 3/4 3/4
Line Size - (in.) O.D. Liquid 3 3/8 3/8 3/8 3/8
Dimensions H x W x D (Crated) 34 x 30.1 x 33 34 x 30.1 x 33 38.4 x 35.1 x 38.7 42.4 x 35.1 x 38.7
Weight - Shipping 200 201 234 228
Weight - Net 173 174 201 193
Start Components YES YES YES NO
Sound Enclosure YES YES YES YES
Compressor Sump Heat NO NO NO NO
Optional Accessories: 4
Anti-short Cycle Timer TAYASCT501A TAYASCT501A TAYASCT501A TAYASCT501A
Evaporator Defrost Control A/C AY28X079 AY28X079 AY28X079 AY28X079
Rubber Isolator Kit BAYISLT101 BAYISLT101 BAYISLT101 BAYISLT101
Crank Case Heater Kit BAYCCHT300 BAYCCHT300 BAYCCHT300 BAYCCHT302
Hard Start Kit Scroll BAYKSKT260
Extreme Condition Mounting Kit BAYECMT023 BAYECMT023 BAYECMT004 BAYECMT004
Snow Leg - Base & Cap 4" High BAYLEGS002 BAYLEGS002 BAYLEGS002 BAYLEGS002
Snow Leg - 4" Extension BAYLEGS003 BAYLEGS003 BAYLEGS003 BAYLEGS003
Seacoast Kit BAYSEAC001 BAYSEAC001 BAYSEAC001 BAYSEAC001
Refrigerant Lineset 5 TAYREFLN950 TAYREFLN7* TAYREFLN7* TAYREFLN7*
1 Certified in accordance with the Air-Source Unitary Heat Pump Equipment certification program which is based on AHRI Standard 210/240.
2 Calculated in accordance with N.E.C. Only use HACR circuit breakers or fuses.
3 Standard line lengths - 80'. Standard lift - 60' Suction and Liquid line.
For Greater lengths and lifts refer to refrigerant piping software Pub# 32-3312-0
†
. (
†
denotes latest revision)
4 For accessory description and usage, see page 5.
5 * = 15, 20, 25, 30, 40 and 50 foot lineset available.
General
Data
Sound Power Level
Model
A-Weighted Sound
Power Level [dB(A)]
Full Octave Sound Power [dB]
63 Hz 125 Hz 250 Hz 500 Hz 1000 Hz 2000 Hz 4000 Hz 8000 Hz
4TTR6018B1 75 51 61 65 74 74 72 61 51
4TTR6024B1 75 49 62 66 74 74 69 62 54
4TTR6030B1 75 54 69 72 78 76 72 64 54
4TTR6036B1 75 49 68 73 76 74 70 62 51
4TTR6042B1 75 49 69 74 77 75 70 62 51
4TTR6048B1 75 49 69 74 77 75 70 62 51
4TTR6049B1 74 70 70 65 64 62 56 49 42
4TTR6060B1 75 49 69 74 77 75 70 62 51
4TTR6061B1 75 68 70 67 68 64 56 53 48
Note:RatedinaccordancewithAHRIStandard270-2008
