SRT Marine
Instruction Manual
SRT-MTB
©
Class B Marine AIS
General arrangement
LD 2111
AIS CLASS B TRANSPONDER
UNIT DIMENSIO NS
2
1:1
1 PRODUCT ION RELEASE 2 3/ 0 2/06
2 BUTTO N C HANG ED TO M EM BRANE SWITC H 15/6 /0 6
10 0,0 30 ,0 1 5 ,0
16 0,0
19 0,0
17 5,0
13 5,020 ,0
16 0,07 ,5
R 8,0
90 ,7
2, 0
O 5,54 H OLES
DRAWN
CHECKED
UNLES S OTHERWISE SPECIFIED
DIMENSI ONS ARE I N M ILLIMETERS
ANGLES ± 0.5 °
0. 0 ± 0.2 0 .0 0 ± 0. 1
NAME
M . KENDA LL
DATE
06/15 /0 6
TITLE
SIZE
A1
DWG NO REV
FILE N AME: LD 21 11- 2. dft
SC AL E:
SHEET 1 OF 1
REVISIO N HISTO RY
REV DESCRIPTI ON DATE APPRO VED
SOFTWARE RADIO TECHNO LOGY PLC
WESTFIELD INDUSTRIAL ESTATE
MIDSOMER NORTON, BATH, UK.
BA3 4BS
C O PY RI GH T
TH IS DRAWIN G IS NOT TO BE REPRO DUC ED
WITHO UT WRITTEN PE RMI SSIO N FRO M SRT PLC .
M ATERIAL
FIN ISH
RUBBER SHEET
1m m THICK
G RADE TO BE DECIDED.
TH IRD AN GLE PRO JEC TIO N
