Transcell Technology TI-500 RF Series User Manual

14
Target weight signal
In this application, relay 1 is activated as soon as the gross or net weight value exceeds the set-
point 1 value. Conversely, relay 1 is de-activated as soon as the gross or net weight value drops
below the set-point 1 value. In this application, the set-point value is an absolute value.
To enter a new set point value:
1. Press the NET/GROSS key.
The display shows the last entered value with the left digit blinking. The pointer for
set-point 1 is on.
2. Press NET/GROSS to accept the old value.
3. The set-point value is activated and the display returns to the weighing mode.
Or
1. Press the NET/GROSS key.
The display shows the last entered value with the left digit blinking. The pointer for
set-point 1 is on.
2. Use the four directional keys to adjust the displayed value to the actual set point. In-
crease the flashing digit by pressing the UNITS key. Decrease the flashing digit by
pressing the ZERO/OFF key. Pressing the TARE key or the ON/PRINT key will
change the position of the flashing digit.
3. After entering the exact value, press the NET/GROSS key to save the value. The
screen displays “SET” briefly. The set-point value is activated and the display returns
to the weighing mode.
Dosing/filling with manual start
In this application, relays 1 and 2 are switched on as soon as the TARE key has been pressed
NOTE: set-point values must have been entered already.
To enter new set-point values:
1. Press the NET/GROSS key.
The display shows the last entered value with the left digit blinking. The pointer for
set-point 1 is on.
2. Press NET/GROSS to accept the old value.
The display shows the last entered value with the left digit blinking. The pointer for
set-point 2 is on.
3. The set-point value is activated and the display returns to the weighing mode.
Or
1. Press the NET/GROSS key.
The display shows the last entered value with the left digit blinking. The pointer for
set-point 1 is on.
2. Use the four directional keys to adjust the displayed value to the actual set point. In-
crease the flashing digit by pressing the UNITS key. Decrease the flashing digit by
pressing the ZERO/OFF key. Pressing the TARE key or the ON/PRINT key will
change the position of the flashing digit.
3. After entering the exact value, press the NET/GROSS key to save the value.
The pointer for set-point 2 is on.
4. After entering the exact value, press the NET/GROSS key to save the value. The
screen displays “SET” briefly. The set-point value is activated and the display returns
to the weighing mode.
