Transduction TR-LCD1900-RM User Manual

TRANSDUCTION 5155 Spectrum Way, Bldg 23, Mississauga, ON L4W 5A1
1.800.268.0427 905.625.1907 Fax: 905.625.0531
www.transduction.com Email: sales@transduction.com
TR-LCD1900-RM-V2
TR-LCD1900-PM-V2
19” Rack Mount LCD Monitor
19” Panel Mount LCD Monitor
Transduction
TR-LCD1900-V2 SVGA, DVI-D, DisplayPort
Specifications:
Reliable LCD Module
Diagonal: 19 inch
Viewable Image Size: 14.90” x 12.00”
Native Resolution (Pixel Count): 1280 x 1024
Active matrix, thin film transistor (TFT) liquid
crystal display (0.294mm dot pitch, 300cd/m
2
white
luminence
Input Signal
SVGA Analog RGB
DVI-D
DisplayPort
Display Colors
Analog input 16,194,277
Maximum Viewing Angles
Up/Down - 75º
Left/Right - 80º
Synchronization Range
Vertical - 15KHz to 80KHz
Horizontal - 50Hz to 77Hz
Resolution
Analog RGB - VGA/SVGA/XGA/SXGA/WXGA/
WUXGA 1280 x 1024 @ 60Hz max.
DVI-D - VGA/SVGA/XGA/ SXGA/WXGA/WUXGA
1280 x 1024 @ 60Hz max.
DisplayPort - VGA/SVGA/XGA/SXGA/WXGA/
WUXGA 1280 x 1024 @ 60Hz max.
Active Display Area
Vertical - 301.056mm
Horizontal - 376.32mm
Power Consumption
60W max.
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
Dimensions
Rack mount: 18.96” (L) x 2.875” (W) x 14” (H) (8U) /
14.3lbs (48.16cm x 7.3cm x 35.56cm / 6.5kg)
Panel mount: 17.75” (L) x 3.00” (W) x 15.25” (H) /
6.5kg - (45.09cm x 7.62cm x 38.74cm / 6.35kg)
Environmental Considerations
Operating Temperature: 0 ~ 50ºC (32 ~ 122ºF), 60ºC
(140ºF) for 2 hours
Operating Humidity 10 ~ 90%, non-condensing
Operating Altitude: 0 to 10,000 ft
Storage Temperature: -20 ~ 60ºC (-4 ~ 140ºF)
Vibration & Shock: 5G and 30G
Storage Humidity: 5 ~ 40%, non-condensing
Regulatory Approvals
CSA, CE, UL
Ordering Information
TR-LCD1900-RM-V2 - Rack Mount version
TR-LCD1900-PM-V2 - Panel Mount version
Warranty: 5 years
Options
TOUCH (Resistive USB)
TOUCH EETI controller
TOUCH ELO controller
Safety glass, no touch
12V DC input power
24V DC input power
48V DC input power
125V DC input power
250V DC input power
TR-LCD1900 series monitors are often used with
Novatech ORION series and SEL Inc. RTAC series of
Linux based RTU’s. Make sure to specify your device
when ordering monitor for the compatibility with touch
screen controller.
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
Page 4 of 37
