Anatomy of the Rustler VXL
Half Shaft
Brushless Motor
(Velineon
™
3500)
Transmission
Spur Gear
Pinion Gear
Slipper Clutch
Electronic Speed Control (VXL-3s)
Battery Compartment
Battery Hold-Down
Receiver
Upper Chassis Plate
Antenna Mount
Suspension
Arm (Front)
Front
Body Mount
Front Bumper
Front
Shock Tower
Steering Servo
(under Upper Chassis Plate)
Shock
(Oil Damper)
Turnbuckle
(Toe Link)
Rear
Shock Tower
Rear Body Mount
Chassis
Turnbuckle
(Front Camber Link )
Suspension
Arm (Rear)
Servo Saver
(not visible)
Traxxas High-
Current Connector
Gear Cover
(ghosted)
Turnbuckle
(Rear Camber Link )
EZ-Set
®
Button (On/Off Button)
Caster Block
Steering Block
