Traynor Small Block 106 - Block Diagram

7
Block Diagram for Small Block SB200H & SB106
BLOCK-DIAG-SMALLBLOCK-SB200H-SB106-00-2v0
DESIGNED AND MANUFACTURED BY YORKVILLE SOUND
MODEL TYPE: YS1109
AMP
Speakon™
Buffer
Inputs
Line & Headphone Outputs
Speaker Outputs
External Speaker
SB200H
1/4-inch TRS
Balanced Tuner Out
(front)
1/4-inch TRS
Phones
1/4-inch
External Speaker
SB106
6.5-inch
Internal Speaker
TRS
1/4-inch
From Rectified AC Line
Power-Off Speaker Mute
TRS
1/4-inch
Mute Circuit
Post-EQ
Pre-EQ
Balanced Line Out
(rear)
MUTE SWITCH
Buffer
GND Sw.
(rear)
0 dB Unbalanced Input
(for passive electronics)
-6 dB Unbalanced Input
(for active electronics)
Mute/
Protect
Red
On
Off
M
M
1+
1-
AUX In
TRS
1/8-inch
Input Gain Pot
EQ
Low / Mid / High
Buffer
EQ
Hi-Mid
Low Expander
Red
Blue
+
Bass 50 Hz Low Mid 400 Hz Hi Mid1 kHz Treble 8 kHz
Tone Control
40 Hz (boost) 550 Hz (cut) 10 kHz (cut)
Low Expander
Block Diagram
