Trejon Optimal - Detailed description

Instructions for Use and Maintenance 120H-HY – 190H-HY (0901)
1.4 Detailed description
1 Chassis
2 Turntable gear, hydraulic powered
3 Adjustable flap
4 Flap control
5 Ejector tube
6 Front safety bow
7 Reversible wearing edge
8 Feeding auger
9 Ejecting rotor
10 Gearbox
11 Hydraulic connection
12 Shear bolt clutch for feeding auger (not in picture)
13 Transmission chain
14 Hydraulic motor
3.
4.
5.
2.
6.
1.
9.
8.
7.
11.
13.
10.
14.
12.
