2022 Checkpoint SL/SLR
19
Specifications
SL SLR
Rear hub OLD 142mm 142mm
Seat post OD 27.2mm
Seat post clamp ID 31.9mm
Seatmast ID 30mm
Upper fork steerer tube OD 28.6mm 28.6mm
Lower fork steerer tube OD 38.1mm 38.1mm
Bottom bracket type/width T47/85.5mm T47/85.5mm
Brake rotor diameter min/
max
140/160mm 140/160mm
Tire width max 700c
(without fenders)
45mm (1.8”) 45mm (1.8”)
Tire width max 650b
(without fenders)
53.5mm (2.1”) 53.5mm (2.1”)
Fender compatible — rear Yes Yes
Fender compatible — front Yes Yes
Rack mount compatible Yes No
Dropper post compatible Yes No
Chainline
Max chainring teeth (T)
Small Large Single (1x)
Shimano GRX
49.7mm 50T
47mm 42T 52T
Shimano 43.5mm 36T 50T
SRAM
45mm 46T
45mm 37T 50T
SRAM WIDE
47.5mm 48T
47.5mm 44T 50T
