2023 Farley 5, 7, and 9
11
Specifications
Chainline (1x only)
76.5mm
Chainring (1x only)
Minimum: 30T
Maximum: 32T
Rear brake mount
Minimum: 160mm
Maximum: 180mm
Maximum tire sizes
26” wheels: 26" x 5.0"
27.5” wheels: 4.5" on 100mm rims
29” wheels: 3.0" is possible, but requires a custom wheel
with a 197mm rear hub
Notice: Measurements of actual tires may vary. Always
verify there is sufcient clearance between the tire and
the frame. Improper tire size could damage the bicycle
frame. Trek recommends 6mm clearance above and on
both sides of the tire.
OLD
Front Hub: 150mm
Rear Hub: 197mm
Water bottle t
Small frame: one water bottle, down tube only.
Water bottles can also be mounted to the underside of the
downtube and to the fork legs.
Bottom bracket
BSA100
Seat post
WARNING
Always follow the seatpost manufacturer’s minimum
insertion recommendation. Failure to follow the recom-
mendation could cause damage to the seatpost and
result in injury to the rider.
3
2
1
1
Maximum
insertion
Small 205mm
Medium 235mm
Large 250mm
Extra-large 270mm
2
Seat tube inside diameter 31.6mm
3
Seat tube post clamp outer diameter 36.2mm
