Trek Farley 5 - Front and Rear Dropout Details

2023 Farley 5, 7, and 9
2
Front and rear dropouts
223mm
22mm
1
2
25Nm
8
3
4
5
NOTICE: Thread must
be at least 12.7mm
1
Switch lever — W573860
2
Thru axle, 12 x 223 — W5279557
3
Derailleur hanger
— W5271425
4
Washer
5
Bolt (left-hand thread)
6
Carbon fork — 5311796
7
Front thru axle, 15 x 198.5mm — W565810
Front dropout (Farley 5 and 9)
7
198.5mm
8mm
6
