Trek ROSCOE 7 - Derailleur Hanger Installation

2022 Roscoe
2
Derailleur hanger
10Nm
1
2
3
4
25Nm
1
Thru axle — W600321
2
Derailleur Hanger
— W600660
3
Washer
4
Bolt
Tools
• 8 mm hex tool
• Torque wrench (left-hand thread) with 8 mm hex bit
WARNING
Do not apply grease to the derailleur hanger or bolt. Only
apply grease to the thru axle.
This bicycle frame is designed to use a Universal Derailleur
Hanger (UDH).
NOTICE: The thru axle must be compatible with a UDH
and must be M12x1.0 with a 12.7 mm thread.
NOTICE: The washer is frame-specic. Install only the
washer compatible with your frame.
NOTICE: Do not over-tighten. Over-tightening the bolt
could cause the hanger to break.
For additional information about the UDH, refer to the
SRAM user manual at www.sram.com.
