Trek ROSCOE 7 - Bicycle Cabling Guide

2022 Roscoe
3
Cabling
1
2
3






5
4
1
Derailleur cable
2
Rear brake hose
3
Dropper post cable
4
Zip tie guide for internal routing — W513977
5
Plug cable guide — W5253075

Zip tie
Zip tie guide
Tips:
• Before inserting the zip tie, bend it in half to create
a crease. This will make it to easier wrap the zip tie
around the cables and out through the hole.
• Use a hook tool and a pick tool to hold the cables and
guide the zip tie around them.
