-19-
T5 - SPARE PARTS LIST v8.0 09/2005
No. Qty. Desc. Ref.
39 1 Collet 6.5mm (UK & EIRE) <05/2005 CLT/T5/635
0 Collet 6.0mm <05/2005 CLT/T5/6
0 Collet 8.0mm (Europe) <05/2005 CLT/T5/8
39A 1 Collet & Nut Set 6.35mm >05/2005 CNS/T5/635
0 Collet & Nut Set 6.0mm >05/2005 CNS/T5/6
0 Collet & Nut Set 8.0mm >05/2005 CNS/T5/8
40 1 Spanner 17mm A/F SPAN/17
41 6 Screw Self Tapping 4mm x 16mm Torx WP-T5/041
42 2 Locking Washer B4 WP-T5/042
44 1 Beam Trammel for 8mm Rod BEAM/005
45 1 Guide Bush 20mm Diameter GB20/B
46 0 Parallel Side Fence Complete with Micro Adjuster WP-T5/046
47 1 Parallel Side Fence Casting >05/2005 WP-T5/047A
48 1 Micro Adjuster Knurled Knob >05/2005 WP-T5/048A
49 1 Side Fence Cheeks (set) >05/2005 WP-T5/049A
50 1 Phenolic Base Plate Slider WP-T5/050
51 4 Machine Screw Cheese M5 x 10mm Slot WP-SCW/50
52 4 Washer 5.3mm x 10mm x 1mm WP-T5/052
53 1 Scale WP-T5/053
55 1 Speed Control Circuit Board 240V T5 & T5/EURO WP-T5E/055
1 Speed Control Circuit Board 115V T5EL WP-T5EL/055
56 1 Speed Control Dial WP-T5E/056
57 1 Insertion Socket WP-T5/057
58 2 Conductor Lead Switch to Speed Control (Blue x 155mm) WP-T5/058
60 1 Spring for Spindle Lock WP-T5/060
61 1 Spindle Lock Body WP-T5/061
62 1 Spindle Lock Plate WP-T5/062
63 1 Screw Self Tapping 4mm x 8mm Torx WP-T5/063
64 1 Washer 20mm x 8mm x 2mm Csk for Column WP-T5/064
65 1 Machine Screw Csk M5 x 10mm Slot WP-T5/065
66 1 Plunge Column Spring WP-T5/066
67 1 Brass Ferrule for Spring WP-T5/067
68 2 Machine Screw Countersunk M5 x 10mm Slot WP-SCW/13
69 1 Rubber Sleeve WP-T5/069
70 1 Lead Field to Speed Control (Red x 90mm) WP-T5/070
71 1 Lead Field to Speed Control (Red x 120mm) WP-T5/071
72 1 Lead Brush to Field (Blue x 90mm) WP-T5/072
73 1 Lead Brush to Field (Blue x 130mm) WP-T5/073
74 1 Dust Extraction Spout WP-T5/074
75 1 Grip Knob Direction Arrow WP-T5/075
76 1 Fixed Grip Knob WP-T5/076
77 0 Side Fence Complete without Micro Adjuster WP-T5/077
78 1 Side Fence Stud M8 x 100mm >05/2005 WP-T5/078A
79 1 Side Fence Washer 24mm x 12mm x 1.6mm WP-T5/079
80 1 Side Fence Half Nut Hex M8 WP-T5/080
81 1 Side Fence Circlip 12mm WP-T5/081
82 1 Side Fence Micro Adjuster Casting WP-T5/082
83 1 Fine Height Adjuster T5EK, T5ELK & T5/EURO FHA/001
84 1 Trigger Lock T5MK2 T5MK2/LOCK
85 1 Manual MANU/T5
MANU-T5 v8.0 1/9/05 12:06 pm Page 19
